Hyundai Sonata III facelift (1996-1998) foglamp relay front foglamp switch Wiring diagram
This page shows the only wiring diagram for the component.foglamp relay front foglamp switch, which is found in the car Hyundai Sonata III facelift (1996-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram foglamp relay front foglamp switch (1 of 1)
116-3
A/C FUSE
A/C RELAY
A/C SWITCH
A/T SHIFT LEVER ILLUM- INATION POWER/ NORMAL SWITCH ILLUM- INATION
ASHTRAY ILLUM- INATION CIGARETTE LIGHTER ILLUMINATION
AUDIO ILLUM- INATION
BLK WIRE
BLOWER FUSE
BLOWER MOTOR
BLOWER RELAY
BLU WIRE
BRN WIRE
CRUISE SWITCH ILLUM- INATION
DAYTIME RUNNING LAMP (DRL) RELAY
DAYTIME RUNNING LAMP CONTROL MODULE RIGHT LICENSE LAMP
ENGINE COMPARTMENT FUSE/RELAY BOX
FOGLAMP RELAY FRONT FOGLAMP SWITCH
FROM FUSIBLE LINK F (DIAGRAM 1 OF 4)
FUSE
FUSIBLE LINK G
FUSIBLE LINK H
GRN WIRE
GRN/WHT WIRE
HEAD- LAMP
HIGH HEADLAMP
IND FUSE
INSTRUMENT CLUSTER
LEFT FRONT PARK/TURN SIGNAL LAMP
LEFT HEADLAMP
LEFT TAILLAMP
LOW HEADLAMP
LT GRN WIRE
NCA WIRE
PASSENGER COMPARTMENT RELAY BOX
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL (OR RED) WIRE
RHEOSTAT (MANUAL A/C ONLY)
RIGHT FRONT PARK/TURN SIGNAL LAMP
RIGHT HEADLAMP
RIGHT REAR COMBINATION LAMP
RIGHT TAILLAMP
TAIL LAMP RELAY
TO MULTI- FUNCTION SWITCH (DIAGRAM 4 OF 4)
USA ONLY
VANITY LAMP POWER DOOR MIRROR SWITCH ILLUMINATION
W/ DRL
W/O DRL
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> FOGLAMP RELAY FRONT FOGLAMP SWITCH
