Car Wiring Diagrams for Charging circuit for Hyundai Sonata III (1993-1996)

ALTERNATOR BATTERY BLK WIRE BLU WIRE CHARGE SYSTEM INDICATOR DASH FUSE BOX FUSE 11 FUSE 12 FUSIBLE LINK 1 (ALT) FUSIBLE LINK B (H/LAMP) FUSIBLE LINK BOX GRN WIRE HOT IN ON OR START INSTRUMENT CLUSTER MAIN FUSIBLE LINK BOX NCA WIRE PNK WIRE POWER DISTRIBUTION SYSTEM REAR DEFOGGER SYSTEM RED WIRE RED/BLK (OR RED) (OR BLU) WIRE RED/BLK WIRE STARTING SYSTEM WHT WIRE WHT/GRN WIRE YEL WIRE
