Car Wiring Diagrams for Cooling fan circuit for Hyundai Sonata III (1993-1996)

0.6 A/C HIGH PRESSURE SWITCH (LEFT FRONT OF ENGINE COMPT) A/C SWITCH AIR CONDITIONING SYSTEM (A/C LOW PRESSURE SWITCH) AIR CONDITIONING SYSTEM (BLOWER RELAY) BLK WIRE BLOWER RELAY BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CONDENSER FAN LOW SPEED RESISTOR (BELOW LEFT HEADLAMP) CONDENSER FAN MOTOR CONDENSER FAN MOTOR RELAY HIGH CONDENSER FAN MOTOR RELAY LOW 1 (ON ENGINE COOLANT FAN) CONDENSER FAN MOTOR RELAY LOW 2 (ON ENGINE COOLANT FAN) DASH FUSE BOX ENGINE COOLANT FAN A/C ON RELAY (ON ENGINE COOLANT FAN) ENGINE COOLANT FAN LOW SPEED RESISTOR (BELOW RIGHT HEADLAMP) 0.4 ENGINE COOLANT FAN MOTOR ENGINE COOLANT FAN MOTOR RELAY HIGH 1 ENGINE COOLANT FAN MOTOR RELAY HIGH 2 (ON ENGINE COOLANT FAN) ENGINE COOLANT FAN MOTOR RELAY LOW 1 ENGINE COOLANT FAN MOTOR RELAY LOW 2 (ON ENGINE COOLANT FAN) ENGINE COOLANT TEMPERATURE SWITCH A (BOTTOM OF RADIATOR) ENGINE COOLANT TEMPERATURE SWITCH B (ON COOLANT OUTLET) FUSE 13 FUSE 20 FUSIBLE LINK BOX (UNDERHOOD) GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/WHT WIRE HEADLIGHT RELAY HOT AT ALL TIMES FUSIBLE LINK 2 HOT AT ALL TIMES FUSIBLE LINK E HOT IN ON IN-LINE DIODE A (RIGHT FRONT CORNER OF ENGINE COMPARTMENT, TAPED IN HARNESS) MAIN FUSIBLE LINK BOX (NEXT TO BATTERY) NCA WIRE RED WIRE RED/BLU WIRE WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE
