Hyundai Sonata III (1993-1996) up/down switch up down down wiring diagram
This page shows the only wiring diagram for the component.up/down switch up down down, which is found in the car Hyundai Sonata III (1993-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
up/down switch up down down wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
DASH FUSE BOX
FUSE 17
GRN WIRE
GRN/RED WIRE
HOT IN ACC OR ON
LEFT
LEFT DOOR MIRROR MOTOR UP/DOWN
LEFT RIGHT
LEFT/RIGHT
LEFT/RIGHT SWITCH RIGHT
MASTER SELECTOR SWITCH
POWER MIRROR SWITCH
RED WIRE
RIGHT DOOR MIRROR MOTOR
UP/DOWN
UP/DOWN SWITCH UP DOWN DOWN
WHT WIRE
YEL WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Power mirror circuit -> UP/DOWN SWITCH UP DOWN DOWN
