Hyundai Sonata III (1993-1996) radio/ cassette player ignition input Wiring diagram
This page shows the only wiring diagram for the component.radio/ cassette player ignition input, which is found in the car Hyundai Sonata III (1993-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram radio/ cassette player ignition input (1 of 1)
1989-91 W/ PREMIUM SOUND SYSTEM
1989-91 W/O PREMIUM SOUND SYSTEM
1989-93 ONLY
1994 SOUND SYSTEM
ANTENNA MOTOR (LEFT SIDE OF TRUNK)
ANTENNA OUTPUT
ANTENNA RELAY
BLK WIRE
BLU/YEL WIRE
BRN WIRE
FUSE 17
GRN (OR GRN/WHT) WIRE
GRN WIRE
HOT AT ALL TIMES DASH FUSE BOX (BELOW LEFT SIDE OF DASH) FUSE 4
HOT IN ACC OR ON
IGNITION INPUT
ORG/ WIRE
RADIO IN-LINE FUSE B (BEHIND CENTER OF DASH)
RADIO/ CASSETTE PLAYER
RADIO/ CASSETTE PLAYER IGNITION INPUT
SOUND SYSTEM
UP SWITCH DOWN SWITCH
UP UP DOWN DOWN
YEL (OR GRN) WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Power antenna circuit -> RADIO/ CASSETTE PLAYER IGNITION INPUT
