Hyundai Sonata III (1993-1996) instrument vehicle speed sensor vehicle speed output cluster Wiring diagram

A/T A/T ONLY BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BRN WIRE CALIFORNIA MODELS ONLY CONDENSER EGR TEMPERATURE SENSOR ENGINE COOLANT TEMPERATURE SENSOR THROTTLE POSITION SENSOR GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE HEATED OXYGEN SENSOR IDLE POSITION SWITCH (TOP RIGHT REAR CORNER OF ENGINE, ON THROTTLE BODY) IDLE SPEED CONTROL MOTOR IGNITION COIL ASSEMBLY (LEFT REAR CORNER OF ENGINE, UNDER INTAKE MANIFOLD) IGNITION COILS INSTRUMENT CLUSTER SYSTEM (TACHOMETER) INSTRUMENT VEHICLE SPEED SENSOR VEHICLE SPEED OUTPUT CLUSTER INTAKE AIR TEMPERATURE SENSOR LT GRN/YEL WIRE M/T NCA WIRE NOISE FILTER (LEFT REAR OF ENGINE, ON VALVE COVER) POWER TRANSISTOR PURGE CONTROL SOLENOID (REAR OF ENGINE COMPT, ON BULKHEAD) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE SOLID STATE SOLID STATE VOLUME AIR FLOW SENSOR SPARK PLUGS STARTER CLUTCH PEDAL POSITION SWITCH STARTER RELAY (IN PASSENGER COMPT RELAY CENTER) STARTING SYSTEM TACH INTERFACE TRANSMISSION SYSTEM TRANSMISSION SYSTEM A/T ONLY LT VOLUME AIR FLOW SENSOR ASSEMBLY WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/RED WIRE YEL/WHT WIRE
