Hyundai Sonata III (1993-1996) electronic spark timing adjust connector Wiring diagrams
This page contains all the electrical diagrams for the component. electronic spark timing adjust connector, in which he is found in the car Hyundai Sonata III (1993-1996). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram electronic spark timing adjust connector (1 of 2)
A/C HIGH PRESSURE SWITCH
BLK WIRE
BLK/WHT WIRE
BRAKE FLUID LEVEL SWITCH
CALIFORNIA ONLY
CONDENSER FAN MOTOR
CONDENSER FAN MOTOR RELAY LOW 1
CRANKSHAFT POSITION SENSOR SHIELD
ECM CONTROL MODULE (ECM)
ECM CONTROL RELAY
ELECTRONIC SPARK TIMING ADJUST CONNECTOR
ENGINE CONTROL MODULE (ECM)
ENGINE COOLANT FAN A/C ON RELAY
ENGINE COOLANT FAN MOTOR
ENGINE COOLANT FAN MOTOR RELAY LOW 1
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE COOLANT TEMPERATURE SWITCH A
ENGINE COOLANT TEMPERATURE SWITCH B
ENGINE SPEED SIGNAL SHIELD
EXHAUST GAS RECIRCULATION TEMPERATURE SENSOR
FRONT WIPER MOTOR
FUSIBLE LINK BOX ABS WARNING LIGHT RELAY
IN-LINE DIODE B
LEFT FRONT FENDER)
LEFT FRONT PARK LIGHT
LEFT FRONT PARK/ TURN LIGHT
ORG/ WIRE
OXYGEN SENSOR
OXYGEN SENSOR SHIELD
POWER TANSISTOR
RIGHT FRONT PARK LIGHT
RIGHT FRONT PARK/ TURN LIGHT
SYSTEM RELAY
TDC SENSOR SHIELD
TDC/CRANK- SHAFT POSITION SENSOR SHIELD
THROTTLE POSITION SENSOR (TP)
VOLUME AIR FLOW (MAF) SENSOR
W/ 3.0L/V6
YEL WIRE
Go to component -> Ground distribution circuit (1 of 6) -> ELECTRONIC SPARK TIMING ADJUST CONNECTOR
Wiring diagram electronic spark timing adjust connector (2 of 2)
-5 -1
A/C SWITCH
A/T ONLY
ACCELERATOR PEDAL SWITCH
BLK WIRE
BLOWER SWITCH
BRAKE FLUID LEVEL SWITCH
COMBINATION SWITCH HEADLIGHT DIMMER/ PASSING SWITCH
CRANKSHAFT POSITION SENSOR
DIGITAL CLOCK
ECM CONTROL MODULE (ECM)
ECM CONTROL RELAY
ELECTRONIC SPARK TIMING ADJUST CONNECTOR
FRESH RECIRCULATE SWITCH
FROM ELECTRIC TIME AND ALARM CONTROL MODULE
FRONT WIPER MOTOR
GLOVE BOX LIGHT
GRN/RED WIRE
HEATER AND A/C CONTROL PANEL
I/P DIMMER SWITCH
IGNITION SHIELD
INSTRUMENT CLUSTER
LIGHT SWITCH
M/T ONLY
MAIN CRUISE SWITCH
OXYGEN SENSOR
OXYGEN SENSOR SHIELD
PASSENGER COMPARTMENT RELAY CENTER
POWER TANSISTOR
REAR WINDOW DEFOGGER SWITCH
RIGHT DOOR LATCH SWITCH
RIGHT FRONT DOOR LOCK ACTUATOR
RIGHT FRONT WINDOW SWITCH
STARTER RELAY
TURN/ HAZARD FLASHER
W/ 2.0L/L4
W/O ANTI-LOCK BRAKES
W/O CRUISE CONTROL
WHT WIRE
WIPER/ WASHER SWITCH
Go to component -> Ground distribution circuit (2 of 6) -> ELECTRONIC SPARK TIMING ADJUST CONNECTOR
