Hyundai Sonata III (1993-1996) combination switch light switch Wiring diagram
This page shows the only wiring diagram for the component.combination switch light switch, which is found in the car Hyundai Sonata III (1993-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram combination switch light switch (1 of 1)
1995 VFTC
BACK-UP LIGHTS
BLK WIRE
BLK/RED WIRE
COMBINATION SWITCH LIGHT SWITCH
DIGITAL CLOCK
FROM BRAKE PEDAL SWITCH
FROM TURN SIGNAL SWITCH
FRONT FENDER)
FUSIBLE LINK B (H/LAMP)
FUSIBLE LINK BOX (RIGHT FRONT OF ENGINE COMP., BEHIND BATTERY)
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
LEFT FRONT FENDER)
LEFT FRONT PARK LIGHT
LEFT FRONT PARK/TURN LIGHT
LEFT TAIL/STOP LIGHT
LEFT TAIL/STOP LIGHT LEFT TAILLIGHT
LICENSE LIGHTS
LT GRN/BLK WIRE
OFF HEAD PARK
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT
RIGHT FRONT PARK LIGHT
RIGHT FRONT PARK/TURN LIGHT
RIGHT TAIL/STOP LIGHT
RIGHT TAILLIGHT
TAIL LAMP (LH) FUSE
TAIL LAMP (RH) FUSE
TAILLIGHT RELAY
TURN LIGHTS
YEL/RED WIRE
Go to component -> Exterior light circuit (1 of 3) -> COMBINATION SWITCH LIGHT SWITCH
