Front heated seats circuit, w/ ventilation for Hyundai Santa Fe V (2023-2024)

BACK POWER BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLOWER POWER BLOWER SPEED BLU WIRE BLU/ORG WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CUSH POWER ECU B+ ECU GND GRN WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES MEMORY POWER MODULE 3 FUSE MODULE 7 FUSE NCA WIRE NTC (-) BLOWER POWER NTC- ORG/ WIRE ORG/BLK WIRE PASSENGER AIR VENTILATION SEAT CONTROL MODULE PDC PDC-D PDC-E POWER DISTRIBUTION SYSTEM RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT END OF DASH) S/HEATER FRT FUSE WHT WIRE WHT/ORG WIRE YEL/BLU WIRE

BACK BLK WIRE BLK/RED WIRE BLU WIRE BLU/ORG WIRE BLU/RED WIRE BRN WIRE CUSH DRIVER AIR VENTILATION SEAT CUSHION BLOWER MOTOR DRIVER CUSHION HEATER DRV VENT SWITCH FLOOR CONSOLE SWITCH GRN WIRE GRY WIRE GRY/BLK WIRE ILL MCU NCA WIRE NTC- ORG/ WIRE ORG/BLK WIRE PASS VENT SWITCH PASSENGER AIR VENTILATION SEAT CUSHION BLOWER MOTOR PASSENGER CUSHION HEATER PNK WIRE POWER RED WIRE RED/BLK WIRE RED/WHT WIRE SPEED VENT/HEATER SWITCH WHT WIRE WHT/ORG WIRE
