Electronic power steering circuit for Hyundai Santa Fe III facelift (2015-2018)

BLK WIRE C-CAN HIGH C-CAN LOW C-CAN TRANSCEIVER COMPUTER DATA LINES SYSTEM E/R JUNCTION BLOCK GRN WIRE GRY WIRE GRY/ORG WIRE HOT AT ALL TIMES HOT IN ON OR START I/P-E I/P-G INSTRUMENT CLUSTER MDPS FUSE MDPS IND MDPS MOTOR MDPS POSITION SENSOR MDPS UNIT MEMORY PWR MICOM MODULE 3 FUSE MOTOR MULTI FUSE NCA WIRE ON/START IN ORG/ WIRE PWM RED WIRE SMART JUNCTION BLOCK SVCC TORQUE, ANGLE SENSOR
