Car Wiring Diagrams for Charging circuit for Hyundai Santa Fe III (2012-2016)

A/V, NAVIGATION HEAD UNIT ALT FUSE ALTERNATOR AMS FUSE BATTERY BATTERY SENSOR BATTERY, BATTERY FUSE BOX BLK WIRE C-CAN TRANSCEIVER CHARGE IND COM COMPUTER DATA LINES ENGINE ROOM RELAY BOX GRN WIRE GRY/ORG WIRE HOT IN ON OR START I/P-G INSTRUMENT CLUSTER LIN LINE MICOM MODULE 3 FUSE ORG/ WIRE PCM RED WIRE SMART JUNCTION BOX SNSR START MOTOR SYSTEM WHT WIRE
