Hyundai Santa Fe III (2012-2016) tail gate open ind Wiring diagrams

B-CAN BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM DOOR OPEN IND DR LOCK FUSE F/LID FUSE FUEL FILLER ACTUATOR FUEL FILLER DOOR SWITCH GRN WIRE GRY WIRE GRY/BLK WIRE HANDLE SWITCH HOT AT ALL TIMES I/P-C I/P-D I/P-F I/P-H INSTRUMENT CLUSTER INTERFACE IPS CONTROL MODULE LEAK CURRENT AUTOCUT DEVICE LICENSE LAMP LOCK SWITCH LOW HIGH M-CAN TRANSCEIVER MEMORY 2 FUSE MICOM MOTOR NCA WIRE OPEN SWITCH PNK WIRE POWER TAIL GATE CINCH ACTUATOR PRIMARY SWITCH RED WIRE RELAY CONTROL SECOND- ARY SWITCH SMART JUNCTION BOX SMART KEY CONTROL MODULE TAIL GATE LATCH TAIL GATE OPEN IND TAIL GATE RELAY TAIL- GATE HANDLE SWITCH TAILGATE) WHT WIRE YEL/BLK WIRE

B-CAN BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM CONTROL DOOR OPEN IND DR LOCK FUSE F/LID FUSE FUEL FILLER ACTUATOR FUEL FILLER DOOR SWITCH GRY WIRE GRY/BLK WIRE HANDLE SWITCH HOT AT ALL TIMES I/P-C I/P-D I/P-F I/P-H INSTRUMENT CLUSTER INTERFACE IPS CONTROL MODULE LATCH RELAY LEAK CURRENT AUTOCUT DEVICE LICENSE LAMP LOW HIGH M-CAN TRANSCEIVER MEMORY 2 FUSE MICOM MOTOR NCA WIRE OPEN SWITCH RED WIRE SMART JUNCTION BOX SMART KEY CONTROL MODULE TAIL GATE LATCH TAIL GATE LATCH RELAY TAIL GATE OPEN IND TAIL GATE OPEN SWITCH TAIL- GATE HANDLE SWITCH TAILGATE) WHT WIRE
