Hyundai Santa Fe III (2012-2016) auto a/c manual a/c w/ smart key w/o smart key Wiring diagram

A/C CONTROL MODULE AMP AUTO A/C MANUAL A/C W/ SMART KEY W/O SMART KEY B-CAN HIGH B-CAN LOW BCM (CENTER OF DASH) BLK WIRE BLU WIRE BLU/BLK WIRE BODY K-LINE BRN/ORG WIRE C- C- CAN CAN HIGH LOW C-CAN HIGH C-CAN LOW CAN CAN LOW HIGH CAN HIGH CAN LOW DATA LINK CONNECTOR (BEHIND LOWER LEFT END OF DASH) DRIVER DOOR MODULE GRN WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN ON OR START I/P-A I/P-F I/P-H IPS CONTROL MODULE K LINE LEAK CURRENT AUTOCUT DEVICE M-CAN HIGH M-CAN LOW MDPS UNIT MEMORY 2 FUSE MODULE 2 FUSE MTS MODULE (RIGHT SIDE OF DASH) ORG/ WIRE ORG/BLK WIRE PASSENGER DOOR MODULE POWER TAILGATE MODULE RED WIRE RED/WHT WIRE SMART JUNCTION BOX SMART KEY CONTROL MODULE SRS CONTROL MODULE TIRE PRESSURE MONITORING MODULE WHT WIRE
