Car Wiring Diagrams for Immobilizer circuit for Hyundai Santa Fe II facelift (2010-2012)

2.4L 3.5L 3.5L 2.4L ANTENNA ANTENNA COIL ANTENNA GROUND BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE BRN/ORG (OR BRN) WIRE BRN/ORG WIRE CLG-A COMM LINE E/R JUNCTION BOX ENGINE CTRL RLY GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ENGINE CONTROL RELAY ON I/P JUNCTION BOX I/P-M IGNITION KEY IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH IMMO DATA LINE CHG-K IMMO IND IMMOBILIZER CONTROL MODULE INSTRUMENT CLUSTER NCA WIRE PCM POWER CONNECTOR ROOM LP FUSE SENSOR 1 FUSE TRANSPONDER U/H-U WHT (OR RED) WIRE WHT/ORG WIRE
