Hyundai Santa Fe II facelift (2010-2012) wheel spd in vcc Wiring diagram
This page shows the only wiring diagram for the component.wheel spd in vcc, which is found in the car Hyundai Santa Fe II facelift (2010-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wheel spd in vcc (1 of 1)
+ECU
2.4L
2.4L 3.5L
3.5L
BLK WIRE
BLU (OR WHT/ WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
CAN HIGH
CAN LOW
CLG-B CHG-K
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR
DIAGNOSIS K-LINE
E/R JUNCTION BOX
ESC 1 FUSE
ESC 2 FUSE
ESC CONTROL MODULE
ESC FUSE
ESC PAS
GRN WIRE
GRN/BLK (OR GRY) WIRE
GRN/BLK WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P JUNCTION BOX
I/P-J
LEFT FRONT WHEEL SENSOR
LEFT REAR COMBINATION LAMP (OUT)
LEFT REAR WHEEL SENSOR
MULTIPURPOSE CHECK CONNECTOR
NCA WIRE
NOTE: ESC CONTROL MODULE CONTAINS: ESC SOLENOIDS, ESC PUMP MOTOR
ORG/ WIRE
ORG/BLK WIRE
PARKING BRAKE SIG
PCM
RED WIRE
RIGHT FRONT WHEEL SENSOR
RIGHT REAR COMBINATION LAMP (OUT)
RIGHT REAR WHEEL SENSOR
STOP LAMP SW
STOP LAMP SWITCH
STOP LP FUSE
U/H-U
VALVE BLOCK RLY
VBATT MOTOR RLY
WHEEL SPD IN SIG
WHEEL SPD IN VCC
WHEEL SPD SENS OUT
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> WHEEL SPD IN VCC
