Hyundai Santa Cruz I (2021-2024) rear driver side impact sensor Wiring diagram
This page shows the only wiring diagram for the component.rear driver side impact sensor, which is found in the car Hyundai Santa Cruz I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear driver side impact sensor (1 of 1)
AIR BAG IND
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
CENTER CONSOLE
COMPUTER DATA LINES SYSTEM
DRIVER CURTAIN AIR BAG
DRIVER SEAT BELT ANCHOR PRETENSIONER
DRIVER SEAT BELT BUCKLE SENSOR
DRIVER SEAT BELT RETRACTOR PRETENSIONER
DRIVER SIDE AIR BAG
DRIVER SIDE IMPACT PRESSURE SENSOR
E-CAN TRANSCEIVER
FRONT DRIVER SIDE IMPACT SENSOR
FRONT PASSENGER SIDE IMPACT SENSOR
GRN WIRE
GROUND
GRY WIRE
GRY/BLK WIRE
INSTRUMENT CLUSTER
MCU
ORG/ WIRE
ORG/BLK WIRE
PASSENGER CURTAIN AIR BAG
PASSENGER SEAT BELT BUCKLE SENSOR
PASSENGER SEAT BELT RETRACTOR PRETENSIONER
PASSENGER SIDE AIR BAG
PASSENGER SIDE IMPACT PRESSURE SENSOR
REAR DRIVER SIDE IMPACT SENSOR
REAR PASSENGER SIDE IMPACT SENSOR
RED WIRE
RED/ORG WIRE
SEAT BELT IND
SIGNAL GROUND
SRS CONTROL MODULE
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (2 of 2) -> REAR DRIVER SIDE IMPACT SENSOR
