Hyundai Santa Cruz I (2021-2024) p position sw sig key interlock sw sig Wiring diagram
This page shows the only wiring diagram for the component.p position sw sig key interlock sw sig, which is found in the car Hyundai Santa Cruz I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram p position sw sig key interlock sw sig (1 of 1)
2.5L
A/T
ASIC
ATM SOLENOID
AUTO LEVER MANUAL
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRAKE LIGHT
BRAKE SWITCH FUSE
BRAKE TEST
BRK LT SW
BRN WIRE
BRN/ORG WIRE
COIL
COMPUTER DATA LINES SYSTEM
DCT
DCT L-CAN HIGH
DCT L-CAN LOW
ESC UNIT ESC MODULE
GRN/BLK WIRE
GROUND
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
IBU (RIGHT SIDE OF DASH)
ICU JUNCTION BLOCK
ICU-A
ICU-B
ICU-C
ICU-D
ICU-E
IPS CONTROL MODULE
KEY INTERLOCK SWITCH
KEY SOLENOID
MANUAL MODE
MEMORY PWR
MODE SWITCH
MODULE 3 FUSE
MODULE 9 FUSE
ON/START INPUT
ORG/ WIRE
ORG/BLK WIRE
P POSITION SW SIG KEY INTERLOCK SW SIG
P POSITION SWITCH
P-CAN HIGH
P-CAN LOW
PNK/BLK WIRE
PTL-CAN HIGH
PTL-CAN LOW
RELAY ENERGIZED
SHIFT LOCK SOLENOID
SPORT MODE SWITCH
STOP LAMP SW
STOP LAMP SWITCH
STOP LP SIG
STOP SIG
SWITCH
SWITCH SIGNAL
W/ SMART KEY
W/O SMART KEY
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Shift interlock circuit -> P POSITION SW SIG KEY INTERLOCK SW SIG
