Hyundai Santa Cruz I (2021-2024) ocv ctrl pnk ccv ctrl Wiring diagram
This page shows the only wiring diagram for the component.ocv ctrl pnk ccv ctrl, which is found in the car Hyundai Santa Cruz I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ocv ctrl pnk ccv ctrl (1 of 1)
A/C RLY CTRL
AIR CONDITIONING SYSTEM
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
CANISTER CLOSE VALVE
CKPS GND
CKPS SIG
CMPS GND
COOLING FANS SYSTEM
ECM (REAR OF ENGINE)
ECTS 2 GND
ECTS 2 SIG
ECTS 3 SIG
ENG CTRL RLY CTRL
ENGINE COOLANT TEMPERATURE SENSOR 1
ENGINE COOLANT TEMPERATURE SENSOR 2
ETC MOTOR, THROTTLE POSITION SENSOR (ON THROTTLE BODY)
ETC MTR
ETC MTR (-) C/FAN PWM CTRL
EWGA MTR O/P (-)
FUEL PUMP RLY CTRL
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
IAT SIG
KNOCK SENS SHIELD
MOTOR
MTR
NCA WIRE
OCV CTRL PNK CCV CTRL WIRE
OIL CONTROL VALVE
OXYGEN SENSOR (DOWN)
OXYGEN SENSOR (UP)
PNK WIRE
PNK/BLK WIRE
POS SENS SIG
RAIL PRESSURE SENSOR
RCV CONTROL SOLENOID VALVE
RCV CTRL
RED WIRE
RED/BLK WIRE
SENS GND
SENS SIG
SENS SIG PRES
THROTTLE POSITION SENSOR
TMM MOTOR
W/ SMART KEY
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Wiring diagram engine performance 2.5l turbo (1 of 6) -> OCV CTRL PNK CCV CTRL WIRE
