Hyundai Santa Cruz I (2021-2024) front wiper low backup switch input Wiring diagram
This page shows the only wiring diagram for the component.front wiper low backup switch input, which is found in the car Hyundai Santa Cruz I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front wiper low backup switch input (1 of 1)
ACC RELAY CONTROL
ANTENNA POWER
AUTO LIGHT SENSOR GROUND
AUTO LIGHT SENSOR SIGNAL
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CRUISE CONTROL SYSTEM
DOOR LOCKS SYSTEM, ANTI-THEFT SYSTEMS
DOOR LOCKS, ANTI-THEFT SYSTEMS
DOOR WARNING SWITCH (OR) SSB SW 2
DRIVER DOOR LOCK/UNLOCK SWITCH
ENGINE CONTROLS SYSTEM
ENGINE RPM
EXTERNAL BUZZER
FRONT WASHER SWITCH INPUT
FRONT WIPER INT/VOL SWITCH
FRONT WIPER LOW BACKUP SWITCH INPUT
FRONT WIPER ON RELAY CONTROL
FRONT WIPER RELAY CONTROL HIGH
FRONT WIPER RELAY CONTROL LOW
FRONT WIPER SWITCH INPUT
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLK WIRE
HEADLAMP HIGH SWITCH SIGNAL
HEADLIGHTS SYSTEM
IBU (RIGHT SIDE OF DASH)
INTERIOR ANTENNA 1 POWER
INTERIOR ANTENNA 2 POWER
KEY HOLE ILL OUT
LIGHT SWITCH SIGNAL
ORG/ WIRE
ORG/BLK WIRE
PASSENGER DOOR LOCK/UNLOCK SWITCH
PNK WIRE
PNK/BLK WIRE
POCKET LAMP
POWER DISTRIBUTION SYSTEM
POWER DISTRIBUTION SYSTEM EXTERIOR LIGHTS SYSTEM
REAR BUMPER ANTENNA POWER
RED WIRE
RED/BLK WIRE
SSB ILL POWER
START FEEDBACK SIGNAL
STARTING/CHARGING SYSTEM
STOP LAMP SWITCH
WARNING SYSTEMS
WHEEL SPEED SENSOR INPUT
WHT WIRE
WIPER PARKING SWITCH
WIPER, LIGHT GROUND
WIPER/WASHER SYSTEM
YEL WIRE
YEL/ORG WIRE
Go to component -> Integrated control unit circuit (2 of 2) -> FRONT WIPER LOW BACKUP SWITCH INPUT
