Hyundai Palisade I (2018-2022) osm select switch folding Wiring diagram
This page shows the only wiring diagram for the component.osm select switch folding, which is found in the car Hyundai Palisade I (2018-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram osm select switch folding (1 of 1)
B-CAN HIGH
B-CAN LOW
B-CAN TRANSCEIVER IC
BCW IND
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN/BLK WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
CTRL C
CTRL HR
CTRL VT
DEFOGGER
DEFOGGER SYSTEM
DEFOGGER TURN LAMP
DEFOGGER, EXTERIOR LIGHTS SYSTEMS
DOWN
DRIVER DOOR CAMERA
DRIVER DOOR MODULE (IN DRIVER DOOR)
DRIVER POWER OUTSIDE MIRROR
FOLDING
FOLDING MIRROR CONTROL
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY/ORG WIRE
HOT W/
HOT W/ LONG TERM LOAD LATCH RELAY ENERGIZED
IBU
ICU JUNCTION BLOCK
ICU-C
JOINT CONNECTOR UDA
LEFT
LEFT RIGHT
M HOR
M VER
MCU
MODULE 4 FUSE
MODULE 9 FUSE
MUF
NAVIGATION SYSTEM
NCA WIRE
ORG/BLK WIRE
OSM POSITION SWITCH LEFT
OSM SELECT SWITCH FOLDING
OUTSIDE MIRROR
PASSENGER DOOR CAMERA
PASSENGER POWER OUTSIDE MIRROR
PNK WIRE
PNK/BLK WIRE
PUDDLE LAMP
PWR
RED WIRE
RED/ORG WIRE
RIGHT
SIG
SYMBOL ILL
TURN LAMP
UP DOWN
VCC
VCC MIRROR MOTOR CONTROL
VOC
VOLTAGE REGULATOR
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Power mirrors circuit -> OSM SELECT SWITCH FOLDING
