Wiring Diagrams for Hyundai Palisade I (2018-2022)

Automatic a/c circuit Manual a/c circuit

Anti-lock brakes circuit

Forced entry circuit Immobilizer circuit, w/o smart key system Immobilizer circuit, w/ smart key system

Body control module circuit Ips control module circuit

Computer data lines circuit

Cooling fan circuit

Cruise control circuit

Defoggers circuit, w/ auto defogger Defoggers circuit, w/o auto defogger

Electronic power steering circuit

Wiring diagram engine performance 3.8l

Backup lamps circuit Exterior lamps circuit

Ground distribution circuit

Autolamps circuit Headlamps circuit

Horn circuit

Head-up display circuit Instrument cluster circuit

Courtesy lamps circuit Instrument illumination circuit

Driver"s memory seat circuit Memory mirrors circuit

Blind spot information system circuit Lane keeping assist circuit Navigation circuit, w/ amplifier Navigation circuit, w/o amplifier Parking assistant circuit Rear view camera circuit Surround view monitor circuit

Power distribution circuit

Power door locks circuit

Electrochromic mirror circuit, w/ home link Electrochromic mirror circuit, w/o home link Power mirrors circuit

Driver power seat circuit Folding seat circuit, second row seats Folding seat circuit, third row seats Heated seats circuit Heated steering wheel circuit Passenger power seat circuit Seat ventilation circuit Second row heated seats circuit Second row seat ventilation circuit

Power top/sunroof circuit

Power windows circuit

Radio circuit, w/ navigation w/ amplifier Radio circuit, w/ navigation w/o amplifier Radio circuit, w/o navigation

Electric parking brake circuit Shift interlock circuit

Charging circuit Starting circuit

Supplemental restraints circuit

A/t circuit Transfer case circuit

Power tailgate circuit Tailgate release circuit

Chime circuit Tire pressure monitoring circuit

Front wiper/washer circuit Rear wiper/washer circuit

ANTI-LOCK BRAKES SYSTEM B-CAN TRANSCEIVER B-CAN TRANSCEIVER IC BATTERY JUNCTION BLOCK C-CAN TRANSCEIVER CENTRAL DOOR LOCK CHILD LOCK CHILD LOCK RLY DOOR LOCK DOOR LOCK/ UNLOCK SIGNAL DRV DOOR LOCK/ DRV DOOR LOCK/UNLOCK SW FULL LOCK HIGH HORN HORN RLY CTRL IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 IGNITION COIL 5 IGNITION COIL 6 IGNITION COIL CONTROL 1 IGNITION COIL CONTROL 2 IGNITION COIL CONTROL 5 IGNITION COIL CONTROL 3 IGNITION COIL CONTROL 4 IGNITION COIL CONTROL 5 IGNITION COIL CONTROL 2 INJECTOR CONTROL 6 HIGH IGNITION COIL CONTROL 6 LIN TRANSCEIVER LOW HORN LR DOOR LOCK/ M-CAN TRANSCEIVER PASS DOOR LOCK/ PASS DOOR LOCK/UNLOCK SW PASS DR LOCK/UNLOCK SW RR DOOR LOCK/ TRANSCEIVER IC UNLOCK LOCK W/ AMPLIFIER WINDOW LOCK WINDOW LOCK IND

AUTO DEFOGGER ACTUATOR BLOWER MOTOR CHECK ENGINE IND CUSHION BLOWER MOTOR PWR CUSHION BLOWER MOTOR SIG DRIVER AIR VENTILATION SEAT BLOWER MOTOR DRIVER BLOWER MOTOR SIG DRIVER CUSHION MOTOR DRIVER DOOR LOCK ACTUATOR DRIVER FRONT HEIGHT ADJUSTER MOTOR DRIVER REAR HEIGHT ADJUSTER MOTOR DRIVER RECLINING MOTOR DRIVER RECLINING MOTOR SIG DRIVER SLIDE MOTOR EMC MOTOR ENGINE CHECK IND ENGINE CONTROLS SYSTEM ENGINE CONTROLS SYSTEM ANTI-THEFT SYSTEM ENGINE CTRL RLY CTRL ENGINE CTRL RLY ON I/P ENGINE RPM ENGINE SPD SIG ETC MOTOR SHIELD ETC MOTOR, +/- FOLDING MOTOR FRONT BLOWER MODE ACTUATOR FRONT BLOWER MOTOR FRONT SUNROOF MOTOR FRONT WIPER MOTOR HAPTIC MOTOR INTAKE ACTUATOR INTAKE ACTUATOR FRE LEFT REAR DOOR LOCK ACTUATOR LEFT REAR POWER WINDOW MOTOR LEFT TEMPERATURE ACTUATOR LH BWD MOTOR LH FWD MOTOR MOTOR SW PWR PASSENGER AIR VENTILATION SEAT BLOWER MOTOR PASSENGER BLOWER MOTOR PWR PASSENGER BLOWER MOTOR SIG PASSENGER DOOR LOCK ACTUATOR PASSENGER FRONT HEIGHT ADJUSTER MOTOR PASSENGER REAR HEIGHT ADJUSTER MOTOR PASSENGER RECLINING MOTOR PASSENGER SLIDE MOTOR REAR BLOWER MODE ACTUATOR REAR BLOWER MOTOR REAR SUNROOF MOTOR REAR TEMPERATURE ACTUATOR REAR WIPER MOTOR RECLINING BLOWER MOTOR RECLINING BLOWER MOTOR PWR RECLINING BLOWER MOTOR SIG RECLINING MOTOR RECLINING MOTOR 1 RECLINING MOTOR 2 RH BWD MOTOR RH FWD MOTOR RIGHT REAR DOOR LOCK ACTUATOR RIGHT REAR POWER WINDOW MOTOR RIGHT TEMPERATURE ACTUATOR RL MOTOR + RR MOTOR - START MOTOR STEERING WHEEL HAPTIC MOTOR SUNROOF MOTOR, CONTROL VCC MIRROR MOTOR CONTROL WASHER MOTOR WIPER MOTOR SIG

ANTENNA 1 GND ANTENNA 1 PWR ANTENNA 2 GND ANTENNA 2 PWR ANTENNA 3 GND ANTENNA 3 PWR BUMPER ANTENNA GND BUMPER ANTENNA GROUND BUMPER ANTENNA POWER BUMPER ANTENNA PWR DRIV DOOR ANTENNA POWER DRV DOOR ANTENNA GND DRV DOOR ANTENNA PWR GROUND ANTENNA 2 GROUND ANTENNA 3 L START INHABIT RLY OUT GROUND ANTENNA 1 LTE ANTENNA PASS DOOR ANTENNA GND PASS DOOR ANTENNA POWER PASS DOOR ANTENNA PWR POWER ANTENNA 1 POWER ANTENNA 2 POWER ANTENNA 3 ROOF ANTENNA SMART KEY BUMPER ANTENNA

START/STOP BUTTON SWITCH VOLTAGE REGULATOR

DOOR CAMERA DOOR CAMERA LH GND DOOR CAMERA LH PWR DOOR CAMERA LH SIG DOOR CAMERA RH GND DOOR CAMERA RH PWR DOOR CAMERA RH SIG DRIVER DOOR CAMERA FRONT VIEW CAMERA FRONT VIEW CAMERA GND FRONT VIEW CAMERA PWR FRONT VIEW CAMERA SIG PASSENGER DOOR CAMERA REAR VIEW CAMERA REAR VIEW CAMERA CIRCUIT REAR VIEW CAMERA GND REAR VIEW CAMERA PWR REAR VIEW CAMERA SHIELD REAR VIEW CAMERA SIG REAR VIEW CAMERA V-GND REAR VIEW CAMERA V-IN W/ BCW/REAR VIEW CAMERA W/O BCW/REAR VIEW CAMERA

DATA LINK CONNECTOR JOINT CONNECTOR UDA JOINT CONNECTOR UDB JOINT CONNECTOR URA MULTI-PURPOSE CHECK CONNECTOR MULTIPURPOSE CHECK CONNECTOR TRAILER CONNECTOR

DRIVER IMS CONTROL MODULE DRIVER MEMORY CONTROL MODULE FRONT A/C CONTROL MODULE FUEL PUMP CONTROL MODULE ICU JUNCTION BLOCK IPS CONTROL MODULE IPS CONTROL MODULE IST AIR VENTILATION SEAT CONTROL MODULE REAR A/C CONTROL MODULE SRS CONTROL MODULE THIRD ROW SEAT FOLDING CONTROL MODULE

+ECU A/V, NAVIGATION HEAD UNIT B+ ECU ECU 1 FUSE ECU 2 FUSE ECU 3 FUSE ECU 4 FUSE ECU 5 FUSE ECU 6 FUSE ECU GND ECU GROUND ESC MODULE ESC UNIT ESC UNIT ESC UNIT ESC MODULE INVERTER UNIT LEFT BLIND-SPOT COLLISION WARNING UNIT MDPS UNIT MEMORY PWR OUTSIDE MIRROR RELAY CONTROL ACC MEMORY POWER ECU MOOD LAMP UNIT POWER TAIL GATE UNIT POWER TAILGATE UNIT RIGHT BLIND-SPOT COLLISION WARNING UNIT SAFETY WINDOW ECU SIDE OF HVAC UNIT) SURROUND VIEW MONITOR UNIT

A/BAG IND FUSE A/C 1 FUSE A/C 2 FUSE A/C FUSE ACC 1 FUSE ACC 2 FUSE ACC 3 FUSE ACC FUSE AIR BAG 1 FUSE AIR BAG 2 FUSE ALT FUSE AMP FUSE AMS FUSE B+1 FUSE B+2 FUSE B+3 FUSE B+4 FUSE B+5 FUSE B/ALARM HORN FUSE BATTERY FUSE BLOCK BLOWER FRONT FUSE BLOWER FRT FUSE BLOWER RR 1 FUSE BLOWER RR 2 FUSE BRAKE SWITCH FUSE CHILD LOCK FUSE CLUSTER FUSE COOLING FAN 2 FUSE DOOR LOCK FUSE DR LOCK FUSE E-SHIFTER 1 FUSE E-SHIFTER 2 FUSE EPB FUSE ESC 1 FUSE ESC 2 FUSE ESC 3 FUSE ESC 4 FUSE FUEL PUMP FUSE FUSE A/C 2 FUSE MODULE-6 HEATED MIRROR FUSE HORN FUSE IBU 1 FUSE IBU 2 FUSE ICU FUSE INVERTER FUSE MDPS FUSE MODULE 1 FUSE MODULE 2 FUSE MODULE 3 FUSE MODULE 4 FUSE MODULE 5 FUSE MODULE 6 FUSE MODULE 8 FUSE MODULE 9 FUSE MODULE 10 FUSE MODULE FUSE MULTI FUSE MULTI FUSE 1 MULTI FUSE 2 OIL PUMP FUSE P/ WINDOW LH FUSE P/ WINDOW RH FUSE P/SEAT PASS FUSE P/WINDOW LH FUSE P/WINDOW RH FUSE POWER OUTLET 1 FUSE POWER OUTLET 2 FUSE POWER OUTLET 3 FUSE POWER OUTLET 4 FUSE POWER TAILGATE FUSE PTC HEATER 1 FUSE PTC HEATER 2 FUSE REAR HEATED FUSE S/HEATER FRT FUSE SUNROOF 1 FUSE SUNROOF 2 FUSE TCU 1 FUSE TCU 2 FUSE TRAILER 1 FUSE WASHER FUSE WIPER FRT 1 FUSE WIPER FRT 2 FUSE WIPER RR FUSE

BACK HEATER CUSH HEATER CUSHION SEAT WARMER HEATER B+ CUSHION SEAT WARMER HEATER GND DRIVER SEAT WARMER HEATER GND HEATER PAD PTC HEATER SEAT WARMER HEATER B+ SEAT WARMER HEATER GND STEERING WHEEL HEATER MODULE STEERING WHEEL HEATING SYSTEM IND

BCW INDICATOR FRONT WIRELESS CHARGER INDICATOR POINTER LED ILL SEAT BELT INDICATOR SECURITY INDICATOR

B-CAN HIGH HEAD LAMP HI SW IN B/UP LAMP SIGNAL BACKUP LAMP CARGO LAMP CENTER ROOM LAMP DEFOGGER TURN LAMP DEFOGGER, EXTERIOR LIGHTS SYSTEMS DRIVER DOOR MOOD LAMP FRONT MOOD LAMP 1 FRONT MOOD LAMP 2 GLOVE BOX LAMP) HAZARD LAMP IND HAZARD LAMP SW GND HAZARD LAMP SW PWR HEAD LAMP LOW SIGNAL HEAD LAMP SIGNAL HEAD- LAMP HIGH MOUNTED STOP LAMP INT TAIL BACKUP LAMP LAMP SW OUT LDS CARGO LAMP LDS ROOM LAMP OUTPUT LED LAMP FAIL IND LEFT FRONT COMBINATION LAMP LEFT MAP LAMP LEFT REAR BUMPER LAMP LEFT REAR DOOR MOOD LAMP LEFT TURN LAMP LEFT VANITY LAMP LICENSE LAMP ASSEMBLY LSD ROOM LAMP OUTPUT OVERHEAD CONSOLE LAMP PASSENGER DOOR MOOD LAMP POCKET LAMP POCKET LAMP GROUND POSITION/ DRL LAMP PUDDLE LAMP PUDDLE/ POCKET LAMP GROUND REAR COMBINATION LAMP LED INPUT RIGHT FRONT COMBINATION LAMP RIGHT MAP LAMP RIGHT REAR BUMPER LAMP RIGHT REAR DOOR MOOD LAMP RIGHT TURN LAMP RIGHT VANITY LAMP SIDE MAKER LAMP STOP LAMP STOP LAMP SIG STOP LAMP SIGNAL STOP LAMP SW SIG T/SIG LAMP SW SIG SW TAIL LAMP TURN LAMP W/ MOOD LAMP W/O MOOD LAMP

ELECTRONIC OIL PUMP FUEL PUMP RLY CTRL HIGH PRESSURE FUEL PUMP

10 ICU-A RELAY CONTROL A/C COMP RELAY A/C COMP RELAY CONTROL A/C RELAY CTRL ACC 1 RELAY ACC 2 RELAY BLOWER FRT RELAY BLOWER RR RELAY BURGLAR ALARM HORN RELAY BURGLAR ALARM HORN RELAY CTRL CHILD LOCK RELAY CHILD UNLOCK RELAY COOLING FAN RELAY CTRL RELAY DOOR LOCK RELAY DOOR UNLOCK RELAY ENGINE CONTROL RELAY FUEL PUMP RELAY HORN RELAY HOT W/ ACC 2 RELAY ENERGIZED HOT W/ ENGINE CONTROL RELAY ENERGIZED HOT W/ LONG TERM LOAD LATCH RELAY ENERGIZED HOT W/ LONG TERM LOAD LATCH RELAY ON ENERGIZED HOT W/ SHORT TERM LOAD LATCH RELAY ENERGIZED ICM RELAY BOX LOAD LATCH RELAY CTRL LONG TERM LOAD LATCH RELAY PTC HEATER 1 RELAY PTC HEATER 2 RELAY REAR DEFOGGER RELAY CTRL REAR DOOR CHILD RELAY REAR HEATED RELAY REAR WIPER RELAY REAR WIPER RELAY CONTROL RELAY CONTROL RELAY CTRL RELAY ENERGIZED SHORT TERM LOAD LATCH RELAY START RELAY START RELAY CTRL SW START RELAY HI SIDE START RELAY LOW SIDE START RELAY WSIG TO LCD T/TURN UNLOCK RELAY T/TURN UNLOCK RELAY CTRL TAIL GATE RELAY TAILGATE RELAY TAILGATE RELAY CTRL VBATT MOTOR RELAY WIPER FRT RELAY WIPER HI RELAY WIPER LO RELAY WIPER MAIN RELAY CONTROL

ACCEL PEDAL POSITION SENSOR AMBIENT TEMP SENSOR AMBIENT TEMPERATURE SENSOR AUTO DEFOGGER SENSOR AUTO LIGHT SENSOR AUTO LIGHT SENSOR GND AUTO LIGHT SENSOR SIGNAL AUTO LIGHT SENSOR SUPPLY AUTO LIGHT, PHOTO SENSOR BATTERY SENSOR BRAKE BOOST VACUUM PRESSURE SENSOR BRAKE FLUID LEVEL SENSOR BRAKE FLUID SENSOR CRANKSHAFT POSITION SENSOR DRIVER FRONT IMPACT SENSOR DRIVER PRESSURE SIDE IMPACT SENSOR DRIVER SIDE IMPACT SENSOR ENGINE COOLANT TEMPERATURE SENSOR ETC MOTOR, THROTTLE POSITION SENSOR EVAPORATOR SENSOR FL SIG WHEEL SENSOR FRONT SENSOR FUEL PRESSURE SENSOR FUEL RAIL PRESSURE SENSOR FUEL TANK PRESSURE SENSOR INCAR TEMPERATURE SENSOR INPUT SPEED SENSOR KNOCK SENSOR 1 KNOCK SENSOR #2 LEFT FRONT CENTER PARKING DISTANCE WARNING SENSOR LEFT FRONT PARKING DISTANCE WARNING SENSOR LEFT FRONT TIRE PRESSURE SENSOR LEFT FRONT WHEEL SENSOR LEFT REAR CENTER PARKING DISTANCE WARNING SENSOR LEFT REAR PARKING DISTANCE WARNING SENSOR LEFT REAR SIDE IMPACT SENSOR LEFT REAR TIRE PRESSURE SENSOR LEFT REAR WHEEL SENSOR LH SENSOR MAP SENSOR MIDDLE SPEED SENSOR MSDI BRAKE FLUID SENSOR OIL PRESSURE SENSOR OIL PRESSURE/ TEMPERATURE SENSOR OIL TEMPERATURE SENSOR OUTPUT SPEED SENSOR PASSENGER FRONT IMPACT SENSOR PASSENGER OCCUPANT DETECTION SENSOR PASSENGER PRESSURE SIDE IMPACT SENSOR PASSENGER SIDE IMPACT SENSOR PHOTO SENSOR PRESSURE SENSOR RAIN SENSOR RAIN SENSOR LIN PNK WIRE REAR OCCUPANT ALERT SENSOR RECLINING SENSOR RH SENSOR RIGHT FRONT CENTER PARKING DISTANCE WARNING SENSOR RIGHT FRONT PARKING DISTANCE WARNING SENSOR RIGHT FRONT TIRE PRESSURE SENSOR RIGHT FRONT WHEEL SENSOR RIGHT REAR CENTER PARKING DISTANCE WARNING SENSOR RIGHT REAR PARKING DISTANCE WARNING SENSOR RIGHT REAR SIDE IMPACT SENSOR RIGHT REAR TIRE PRESSURE SENSOR RIGHT REAR WHEEL SENSOR SENSOR 1 FUSE SENSOR 2 FUSE SENSOR 4 FUSE SENSOR 5 FUSE SENSOR 6 FUSE SENSOR GROUND SENSOR SUPPLY THROTTLE POSITION SENSOR VCC SENSOR WASHER LEVEL SENSOR WHEEL SENSOR

CENTER SPEAKER CLUSTER SPEAKER DRIVER DOOR SPEAKER DRIVER DOOR TWEETER SPEAKER LEFT REAR DOOR SPEAKER LEFT REAR DOOR TWEETER SPEAKER LEFT SURROUND SPEAKER PASSENGER DOOR SPEAKER PASSENGER DOOR TWEETER SPEAKER RIGHT REAR DOOR SPEAKER RIGHT REAR DOOR TWEETER SPEAKER RIGHT SURROUND SPEAKER SPEAKER OUT - WOOFER SPEAKER

AC SWITCH IN AC SWITCH OUT AJAR SWITCH AUTO HOLD SWITCH BCW SWITCH BI-FUNCTION H/LAMP LOW TELL-TALE SWITCH BLOWER SWITCH BRAKE LIGHT SWITCH CHILD LOCK SWITCH CONTROL SWITCH CRASH PAD SWITCH DBC SWITCH DEF SWITCH DOOR LOCK SWITCH DOOR SWITCH DOOR SWITCH SIGNAL DOOR WARNING SWITCH DRIVER CUSHION SWITCH DRIVER DOOR SWITCH DRIVER FRONT HEIGHT ADJUSTER SWITCH DRIVER LEFT SEAT BELT BUCKLE SWITCH DRIVER REAR HEIGHT ADJUSTER SWITCH DRIVER RECLINING LIMIT SWITCH DRIVER RECLINING SWITCH DRIVER SEAT BELT BUCKLE SWITCH DRIVER SEAT MANUAL SWITCH DRIVER SLIDE SWITCH ELECTRIC PARKING BRAKE SWITCH ELECTRONIC ATM SHIFT LEVER SWITCH ESC OFF SWITCH FOG LAMP SWITCH IN FOLDING SWITCH FRONT CONSOLE SWITCH FRONT SUNROOF SWITCH FRONT WASHER SWITCH SIG FULL LOCK SWITCH FULL OPEN SWITCH GLOVE BOX LAMP/ SWITCH HALF LOCK SWITCH HANDLE SWITCH HAZARD LAMP SWITCH HAZARD LAMP SWITCH IND HAZARD SWITCH HIGH IND SWITCH HOOD SWITCH HORN SWITCH IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH IGNITION SWITCH IMS SWITCH INHIBITOR SWITCH INPUT SWITCH INT/VOL SWITCH ISG SWITCH LEFT REAR DOOR SWITCH LEFT REAR POWER WINDOW SWITCH LEFT STEERING WHEEL REMOTE CONTROL SWITCH LEFT VANITY LAMP SWITCH LH LIMIT SWITCH BWD LIGHT SWITCH SIG LIGHT SWITCH SIGNAL LIMIT SWITCH LKA-L SWITCH LOCK SWITCH LOW IND SWITCH LR DOOR SWITCH MEMORY SWITCH MID IND SWITCH MTS SWITCH MULTI- FUNCTION SWITCH OIL PRESSURE SWITCH OPEN SWITCH OSM POSITION SWITCH LEFT OSM SELECT SWITCH OSM SELECT SWITCH FOLDING PARKING SWITCH PASSENGER DOOR SWITCH PASSENGER POWER WINDOW SWITCH PASSENGER RECLINING LIMIT SWITCH PASSENGER SEAT BELT BUCKLE SWITCH PASSENGER SEAT MANUAL SWITCH PDW/RPDW SWITCH PDW/RPDW SWITCH IND REAR DEFOGGER SWITCH REAR DEFOGGER SWITCH INPUT REAR POWER WINDOW SWITCH LH SIGNAL REAR POWER WINDOW SWITCH RH SIGNAL REAR SUNROOF SWITCH REAR VIEW SWITCH REAR VIEW SWITCH SIGNAL REAR WASHER SWITCH SIGNAL REAR WINDOW LOCK SWITCH SIGNAL REAR WIPER SWITCH SIGNAL RECLINING LIMIT SWITCH RH LIMIT SWITCH BWD RIGHT REAR DOOR SWITCH RIGHT REAR POWER WINDOW SWITCH RIGHT STEERING WHEEL REMOTE CONTROL SWITCH RIGHT STEERING WHEEL REMOTE CONTROL SWITCH STEERING WHEEL RIGHT VANITY LAMP SWITCH RR DOOR SWITCH SEAT BELT BUCKLE SWITCH INPUT SEAT BELT BUCKLE SWITCH INPUT DRIVER STEERING WHEEL HEATED SWITCH STEERING WHEEL HEATED UNLOCK SWITCH STEERING WHEEL HEATER SWITCH IND STOP LAMP SWITCH SVM SWITCH SW SWITCH SWITCH SIGNAL TAILGATE FULL LOCK SWITCH TAILGATE FULL OPEN SWITCH TAILGATE HANDLE SWITCH TAILGATE OPEN SWITCH WALK IN SWITCH WARMER SWITCH WARMER SWITCH HIGH IND WARMER SWITCH LOW IND WARMER SWITCH MID IND WARMER SWITCH SW WIPER B/UP SWITCH SIGNAL

CANISTER CLOSE VALVE ELECTRO MAGNETIC VALVE CLUTCH ELECTRONIC CONTROL VALVE ELECTRONIC A/C COMPRESSOR KEY SOLENOID KEY SOLENOID DRIV DR ANTENNA GND PURGE CONTROL SOLENOID VALVE START SOLENOID VARIABLE INTAKE SOLENOID VALVE 1 VARIABLE INTAKE SOLENOID VALVE 2 VOLUME CONTROL VALVE HIGH VOLUME CONTROL VALVE LOW

3 4 PNK WIRE (OR RED/ WIRE B+ O/P PNK ACC/ON O/P WIRE B-CAN LO PNK B-CAN HI WIRE BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/ORG WIRE BRN/RED WIRE BRN/WHT WIRE GREEN CONTROL GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/ORG WIRE HEAD LAMP HIGH SWITCH IN PNK FRONT WIPER SWITCH SIGNAL WIRE LED GREEN LT GRN WIRE LT GRN/BLK WIRE M/LOW PNK WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE PDW/RPDW SWITCH SIGNAL PNK SUNROOF OPEN SIGNAL WIRE PNK B-CAN HI WIRE PNK DRIV DR LOCK/UNLOCK SW WIRE PNK LO WIRE PNK MEMORY POWER WIRE PNK ON IN WIRE PNK SUPPLY SENS WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/ORG WIRE RED/WHT WIRE RED/YEL WIRE SIG PNK IAT SENS WIRE VIO WIRE WHITE CONTROL WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/ORG WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/ORG WIRE YEL/RED WIRE YEL/WHT WIRE

3.5 INCH MONO LCD 7 INCH TFT LED 12-WAY 10-WAY "ON" 'B' OUTPUT 'P' POSITION SIGNAL (BELOW RIGHT SIDE OF DASH (CENTER (LEFT SIDE -SET CANCEL A/C IND OUT A/C PRESSURE TRANSDUCER ABS IND. AC IND IN AC INVERTER OUTLET ACC/ ON ACC/ON I/P ACC/ON IN ACC/ON INPUT ACC/ON O/P AIR BAG IND AIR CONDITIONING SYSTEM AM/FM B+ AM/FM OUT ANT B+ ANT-A ANTI-THEFT SYSTEM APS 1 GND APS 1 GROUND APS 1 SIG APS 1 SIGNAL APS 1 SUPPLY APS 2 GND APS 2 GROUND APS 2 SIG APS 2 SUPPLY ARISU CAN AST WINDOW AUTO DOWN AST WINDOW AUTO UP AST WINDOW DOWN AST WINDOW UP AUTO DOWN AUTO HIGH BEAM IND AUTO LT SENS GND AUTO LT SENS SIG AUTO LT SENS SUPPLY AUTO UP AUTOMATIC A/C AVN SIG B+1 B+4 B+ ENABLE B+ LIN B+ PWR B-CAN B-CAN HI B-CAN HIGH B-CAN LO B-CAN LOW B-CAN LW B-LOW B-HIGH BACK UP SW OUT BACKUP LAMPS CIRCUIT BACKUP LP BACKUP SIG BACKUP SIGNAL BCW IND BCW ON/OFF SW BELT PASS BLOWER COMMON BLOWER MAX ON SIG BPF LNA BRAKE LIGHT SW BRAKE LP LH BRAKE LP LH TAIL LP RL BRAKE LP RH BRAKE SIGNAL BRAKE TEST SW BURGLAR ALARM C-CAN C-CAN HI C-CAN HIGH C-CAN LO C-CAN LOW C-HIGH C-LOW CCP CAN HI CCP CAN LO CCP-CAN HIGH CCP-CAN LOW CCV CONTROL CENTER FASCIA KEYBOARD CENTRAL DOOR UNLOCK CHARGE IND CHILD UNLOCK RLY CINCHING MTR + CLEAN SIG CLINCHING MTR - CLOCK- SPRING CLUSTER IONIZER COAXIAL CABLE COMMON GND COMMUNICATION LIN COMPUTER DATA COMPUTER DATA LINES COMPUTER DATA LINES SYSTEM CONSTANT CURRENT COOLING FAN COOLING FAN CONTROLLER COOLING FAN PWM O/P COOLING FANS SYSTEM CRASH OUTPUT CRASH SIGNAL CRASH UNLOCK CRUISE CONTROL SYSTEM CRUISE ON/OFF CRUISE ON/OFF RES+ CTRL C CTRL HR CTRL VT D VFS D VFS 28 D VFS 46 D VFS UD D-CAN HI D-CAN LO D-HIGH D-LOW DATA LINE DATA LINES DEDI DRL LH DEDI DRL RH DEFOGGER REAR DEFOGGER SYSTEM DETENT OUT DIAGNOSIS CIRCUIT DIAL LED ILL DIRECTION DOWN VCC DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM ANTI-THEFT SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR UNLOCK DOWN GND DOWN UP DOWN_IN DRIVE MODE DRIVE MOOD CIRCUIT DRIVER AIR BAG 1 DRIVER AIR BAG 2 DRIVER COOL DRIVER CURTAIN AIR BAG DRIVER CUSHION MTR BWD DRIVER CUSHION MTR FWD DRIVER CUSHION MTR SIG DRIVER DOOR MODULE DRIVER KNEE AIR BAG DRIVER POWER OUTSIDE MIRROR DRIVER RECLINING MTR BWD DRIVER SAFETY POWER WINDOW MODULE DRIVER SEAT DRIVER SEAT BELT PRETENSIONER DRIVER SEAT WARMER DRIVER SIDE AIR BAG DRIVER SMART KEY OUTSIDE HANDLE DRIVER WARMER DRIVER WINDOW DRIVER WINDOW DOWN DRIVER WINDOW UP DRV CURTAIN AIR BAG HIGH DRV CURTAIN AIR BAG LOW DRV CUSHION SW BWD DRV CUSHION SW FWD DRV DOOR DRV FRONT HEIGHT ADJ MTR DWN DRV FRONT HEIGHT ADJ MTR SIG DRV FRONT HEIGHT ADJ MTR UP DRV FRONT HEIGHT ADJ SW DN DRV FRONT HEIGHT ADJ SW UP DRV LUMBAR SUPPORT SW BWD DRV LUMBER SUPPORT SW DN DRV LUMBER SUPPORT SW FWD DRV LUMBER SUPPORT SW UP DRV PRESS SIDE IMPACT SENS HIGH DRV PRESS SIDE IMPACT SENS LOW DRV REAR HEIGHT ADJ MTR DWN DRV REAR HEIGHT ADJ MTR SIG DRV REAR HEIGHT ADJ MTR UP DRV REAR HEIGHT ADJ SW DN DRV REAR HEIGHT ADJ SW UP DRV RECLINING MTR FWD DRV RECLINING SW BWD DRV RECLINING SW FWD DRV SEAT BELT PRETENSIONER HIGH DRV SEAT BELT PRETENSIONER LOW DRV SIDE AIR BAG HIGH DRV SIDE AIR BAG LOW DRV SIDE IMPACT SENS HIGH DRV SIDE IMPACT SENS LOW DRV SIDE MTR BWD DRV SIDE MTR FWD DRV SLIDE MTR SIG DRV SLIDE SW BWD DRV SLIDE SW FWD E/R JUNCTION BLOCK E/R-A E/R-B E/R-C EC MIRROR CONTROL ECTS GND ECTS SIG ELECT A/C COMPRESSOR IN ELECT A/C COMPRESSOR OUT ELECTRO- CHROMIC MIRROR ELECTROCHROMIC MIRROR ELECTRONIC THERMOSTAT EMS COM ENCODER 1 ENCODER 2 ENCODER 2 ENCODER 1 ENCODER SENS GND ENCODER SENS PWR ENG SPD EPB IND ESC IND ESC MODULE ESC OFF IND EXTERNAL BUZZER FCA IND FCA OFF IND FEEDBACK SIG FL SIG FL VCC FOLDING MIRROR CONTROL FPS IN FPS SUPPLY FR FR RR RH RR RH LH LH FR SIG FR T/SIG LH FR T/SIG RH FR VCC FRONT A/C CONSOLE MODULE FRONT A/C FASCIA KEYBOARD FRONT WASHER FRONT WASHER SW SIG WIPER B/UP SW SIG FRONT WIPER FRONT WIPER LOW FRONT WIPER RLY CTRL HI FRONT WIPER RLY CTRL HIGH FRONT WIPER RLY CTRL LO FRONT WIPER RLY CTRL LOW FRONT WIPER SW FRONT WIRELESS CHARGER FRT A/C CTRL MOD FRT BLWR MODE ACTR FUEL GAUGE TACHOMETER FUEL SENDER FULL LOOK SW FWD DOWN GLASS STATUS SIGNAL GLASS TEMP GND REAR WIPER GND SENS GND SIG 1 GND SIGNAL 1 GPS OUT/B+ GPS OUT/VIN GROUND DISTRIBUTION SYSTEM H/LP HI LH H/LP LO RH H/LP HI RH H/LP LO LH HALF LOOK SW HALL SENS HANDLE) HAZARD SW HDLP HI SW IN HDLP HIGH SW IN WIPER, LIGHT GND HDLP HIGH SW OUT HDLP LOW BACKUP SW OUT HDLP LOW SIG HEAD-UP DISPLAY HEADLAMP LOW SIGNAL HEADLAMP TAIL HEADLIGHTS SYSTEM HIGH BEAM IND HIGH IND HIGH SW OUT HOME LINK HOME POS SW GND HOME POS SW SIG HORNS SYSTEM HOT AT ALL TIMES HOT IN ON HOT IN ON OR START HOT W/ HS CAN+ I-CAN HI I-CAN HIGH I-CAN LO I-CAN LOW I-HIGH I-LOW ICU ENABLE ICU JUNCTION BLOCK ICU-A ICU-B ICU-C ICU-D ICU-E ICU-F ICU-G ICU-G ICU-F IGN 1 ILL PWR IMMO DATA LINE IMMO GND IMMO IND IMMO KLINE IMMO PWR INCAR TEMP SENS MOTRO INCAR TEMP SENS SIG IND ISG SW IND SW SENS INJECTOR 1 INJECTOR 2 INJECTOR 3 INJECTOR 4 INJECTOR 5 INJECTOR 6) INJECTOR CONTROL 1 HIGH INJECTOR CONTROL 1 LOW INJECTOR CONTROL 2 HIGH INJECTOR CONTROL 2 LOW INJECTOR CONTROL 3 HIGH INJECTOR CONTROL 3 LOW INJECTOR CONTROL 4 HIGH INJECTOR CONTROL 4 LOW INJECTOR CONTROL 5 HIGH INJECTOR CONTROL 5 LOW INPUT CAPTURE INPUT SPEED SIGNAL INPUT SPEED SUPPLY INSTRUMENT CLUSTER INSTRUMENT CLUSTER SIG INSTRUMENT CLUSTER SYSTEM INT LO INT TAIL INT/VOL SW INTAKE ACTR IONIZER DIAG IPS 1 IPS 2 IPS 3 IPS 8 IPS 10 IPS 11 IPS 15 ISG SIG KEY HOLE ILL OUT KEY PAD GND KEY PAD SIG KEYPAD GND KEYPAD PWR KEYPAD RESET KLINE IMMO L LF IN L START INHIBIT RLY OUT L-CAN HIGH L-CAN LOW LED DRIVER LED ILL LEFT "C" PILLAR) LEFT ANTI-PINCH LEFT CTRL LEFT HEADLAMP LEFT REAR WINDOW DOWN LEFT REAR WINDOW UP LEFT RIGHT LEFT TURN IND LEFT/ RIGHT UP/ DOWN LF SEARCHING ON OUT LH ANTI-PINCH GND LH BCW IND LH FOLDING LH HALL SENS SPIN MTR GND LH HALL SENS SPIN MTR POWER LH HALL SPIN MTR SENS 1 LH HALL SPIN MTRSENS 2 LH SPIN MTR - LH TEMP ACTR COOL LH TEMP ACTR WARM LH UNFOLDING LID 1 LID 2 LID 3 LIGHT GND LIGHT SW LIGHT SW OUT LIGHT SW SIG LIN LINE LIN PDW LIN-COMM LINE IMMO LINES SYSTEM LKA-L SW LOCAL CAN HIGH LOCAL CAN LOW LONG TERM LOW BEAM IND LOW DC-DC CONVERTER LOW FUEL IND LOW HIGH LOW IND LOW SIG LOW TELL-TALE LP LOAD AUTCUT LR DOOR CHILD LR SIDE IMPACT SENS HIGH LR SIDE IMPACT SENS LOW LS CAN LTE 1 LTE 2 LTE DIV LTE OUT LUGGAGE POWER OUTLET M HOR M VER M-CAN M-CAN HI M-CAN HIGH M-CAN LO M-CAN LOW M-CAN LW M-LOW M-HIGH MANUAL A/C MASTER IND MATCHING CIRCUIT MATCHING LNA CIRCUIT MDPS IND MEM POWER MEM PWR MEMORY POWER MEMORY POWER POWER MEMORY PWR MIC - MIC SHIELD MID IND MIDDLE SPEED SIGNAL MIDDLE SPEED SUPPLY MIRRORS SYSTEM MIRRORS SYSTEM WIPER/WASHER SYSTEM MONO LCD 3.5 INCH MTR GND MTS KEY PAD SIG NAVIGATION SYSTEM NAVIGATION SYSTEM ANTI-THEFT SYSTEM NOT USED NTC- OD, LR OF DASH) OIL PRESSURE IND OIL TEMP SENS OIL TEMPERATURE OK DOWN ON IN ON INPUT ON START I/P ON START INPUT ON/START I/P ON/START IN ON/START INPUT ON/STAT INPUT OPEN SW OUTPUT B+ OUTPUT SPEED SIGNAL OUTPUT SPEED SUPPLY OUTSIDE MIRROR OUTSIDE MIRROR CONTROL OUTSIDE MIRROR CONTROL C OUTSIDE MIRROR CONTROL HR OUTSIDE MIRROR CONTROL VT P POS SIG P-CAN P-CAN HI P-CAN HIGH P-CAN LO P-CAN LOW P-CAN LOW ON/START INPUT GND P-LOW P-HIGH PAB OFF PAB OFF IND PADD DOWN PADD UP PARKING BRAKE IND. PASS ACTIVE A/BAG HIGH PASS ACTIVE A/BAG LOW PASS CURTAIN AIR BAG HIGH PASS CURTAIN AIR BAG LOW PASS DOOR PASS PRESS SIDE IMPACT SENS HIGH PASS PRESS SIDE IMPACT SENS LOW PASS SEAT BELT BUCKLE SW PASS SEAT BELT PRETENSIONER HIGH PASS SEAT BELT PRETENSIONER LOW PASS SIDE AIR BAG HIGH PASS SIDE AIR BAG LOW PASS SIDE IMPACT SENS HIGH PASS SIDE IMPACT SENS LOW PASSENGER AIR BAG 1 PASSENGER AIR BAG 2 PASSENGER AIR BAG 3 PASSENGER COOL PASSENGER CURTAIN AIR BAG PASSENGER POWER OUTSIDE MIRROR PASSENGER REAR RH PASSENGER SAFETY POWER WINDOW MODULE PASSENGER SEAT BELT IND PASSENGER SEAT BELT PRETENSIONER PASSENGER SEAT WARMER PASSENGER SIDE AIR BAG PASSENGER SMART KEY OUTSIDE HANDLE PASSENGER WARMER PCB BLOCK PCSV CONTROL PHASE U PHASE V PHASE W PLACE IN CAPITAL LETTERS POWER DISTRIBUTION SYSTEM POWER GROUND POWER TAILGATE BUZZER POWER TAILGATE LATCH POWER TAILGATE OPEN SW TAILGATE OPEN SW POWER TOPS SYSTEM POWER WINDOWS SYSTEM POWER WINDOWS, SUNROOF SYSTEMS PRESSURE SENS GND PRESSURE SENS PWR PRESSURE SENS SIG PULSE GND PWM OUTPUT PWR GND RAIN SENS LIN REAR DEFOGGER REAR DOOR) REAR WASHER REAR WASHER SW SIG REAR WIPER REAR WIPER SW SIG REAR WIPER/ WASHER SYSTEM RECLINING WARMER B+ RECLINING WARMER GND RECLINING WARMER GND PWR RES+ RESET+ RF SIGNAL RH ANTI-PINCH GND RH ANTI-PINCH POWER LH ANTI-PINCH POWER RH BCW IND RH FOLDING RH HALL SENS SPIN MTR GND RH HALL SENS SPIN MTR POWER RH HALL SPIN MTR SENS 1 RH HALL SPIN MTRSENS 2 RH SPIN MTR + RH SPIN MTR - 15 16 LH SPIN MTR SHIELD RH SPIN MTR SHIELD RH UNFOLDING RHEOSTAT DOWN IN RHEOSTAT UP IN RIGHT ANTI-PINCH RIGHT END OF DASH) RIGHT HEADLAMP RIGHT REAR WINDOW DOWN RIGHT REAR WINDOW UP RIGHT TURN IND RING ILL RL SIG RL VCC RLY CTRL RLY CTRL ACC RR A/C CTRL MODULE RR DOOR CHILD RR SIDE IMPACT SENS HIGH RR SIDE IMPACT SENS LOW RR SIG RR T/SIG LH RR T/SIG RH RR VCC RR VIEW SW SIG S GND S-FLASH MEMORY SAFETY POWER WINDOW ENABLE SAFETY POWER WINDOW ENABLE OUT SCU SHIELD SEAT BELT IND SEATS SYSTEM SECURITY IND SENS GND SENS POWER SENS PWR SENS SIG SENS SUPPLY SET- SHIELD SENS SHIFT INTERLOCK SYSTEM SHIFT SOL SS-A SHORT TERM SIG GND 1 SIG GND 3 SIG IN SIG OUT SIGNAL IN SIGNAL OUT SIGNAL PRESSURE OIL SMART CRUISE CONTROL RADAR SOL POWER A SOL PWR B SOUND SYSTEMS SPDIF GND SPEED OUT SPEED SIGNAL SR MTR PWR HSD SSB ILL POWER SSB ILL PWR SSB RING SSB RING ILL OUT SSB SW 1 SSB SW 2 START FEEDBACK SIGNAL START MTR CTRL SW START RLY START RLY HIGH SIDE START RLY LOW SIDE STARTING CIRCUIT STARTING/ CHARGING SYSTEM STARTING/CHARGING SYSTEM STATUS IND STEERING HEAT STEERING WHEEL HEATED STEERING WHEEL HEATED MODULE STEERING WHEEL) STOP SIG SUPPLEMENTAL RESTRAINTS SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM WIPER/WASHER SYSTEM SUPPLY SENS SVM SW I/P SVM SW IND SW 1 SW 2 SW 3 SW 4 SW GND SW IND SW OUT SW SIG SXM OUT/VIN SYMBOL ILL SYS GND T/TURN UNLOCK TAIL EXT FRT LH TAIL EXT FRT LH DEDI DRL RH TAIL EXT FRT RH TAIL LP RL TAIL LP RR TAIL ON IND TAILGATE FULL TAILGATE LATCH TAILGATE OPEN SW ILL TAILGATE) TELL TAIL TURN FR LH TELL TAIL TURN FR RH TELL TAIL TURN RR LH TELL TAIL TURN RR RH TELL TALE TELLTAIL H/LP LOW TELLTAIL TURN TEMP ACTR TEMPERATURE GAUGE TEST SW TFT LCD DRIVE TILT UP TOP OF RIGHT CYLINDER HEAD COVER) TPMS IND TPS 1 SIG TPS 1 SIGNAL TPS 2 SIG TPS 2 SIGNAL TPS GND TPS GROUND TPS SUPPLY TRANSMISSIONS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM TURN LEFT TURN RIGHT TURN SIGNAL UNLOCK SIG UP DOWN UP GROUP UP_IN USB ACC USB D- USB GND USB JACK V GND V IN V OUT VEH SPD SIG VEHICLE SPD VEHICLE SPEED VFS LP VFS T/CON VIDEO SIG VIDEO+ VOL 2 VOL 3 VOL 4 W/ AIR VENTILATION SEAT W/ AUDIO W/ BCM W/ BCW W/ CONVENTIONAL W/ IMMOBILIZER W/ LED W/ MEMORY W/ MEMORY W/O MEMORY W/ NAVIGATION W/ NAVIGATION MANUAL A/C W/ NAVIGATION SYSTEM W/ POWER SEAT W/ POWER SEAT SEAT W/ POWER TAILGATE W/ SEAT WARMER W/ SMART KEY W/ SMART KEY W/O SMART KEY W/ SURROUND VIEW W/ SURROUND VIEW MONITOR W/O AIR VENTILATION SEAT W/O AIR VENTILATION SEAT W/ AIR VENTILATION SEAT W/O IMMOBILIZER W/O LED W/O LED W/ LED W/O MEMORY W/O NAVIGATION W/O NAVIGATION SYSTEM W/O POWER SEAT SEAT W/O POWER TAILGATE W/O SMART KEY W/O SMART KEY W/ SMART KEY W/O SURROUND VIEW WARNING SENS PWR WARNING SYSTEMS WHEEL) WIPER 'P' POSITION WIPER LOW WIPER MAIN RLY CTRL WIPER, LIGHT GND WIPER, LIGHT GROUND WIPER/WASHER SYSTEM
