Hyundai Kona I facelift (2020-2024) lh hdlp low telltale sw sig Wiring diagram
This page shows the only wiring diagram for the component.lh hdlp low telltale sw sig, which is found in the car Hyundai Kona I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lh hdlp low telltale sw sig (1 of 1)
2.0L
B-CAN HIGH
B-CAN LOW
BCM (RIGHT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE SW FUSE
BRAKE SWITCH FUSE
BRAKE/
COMPUTER DATA LINES SYSTEM
ECM (1.6L TURBO) PCM (2.0L)
ESC CONTROL MODULE
GATEWAY
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P-A
I/P-C
I/P-F
I/P-G
IGPM
IPS CONTROL MODULE
LEFT HEADLAMP
LH HDLP LOW TELLTALE SW SIG
LIGHT SW
LIGHT SWITCH SIG
MODULE 3 FUSE
NCA WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
RH HDLP LOW TELLTALE SW
RIGHT HEADLAMP
SMART KEY CONTROL MODULE
STOP LAMP
STOP LAMP SW
STOP LAMP SWITCH
TELLTALE
TEST SW
W/ EPB W/O EPB
W/ LED HEADLAMPS
WIPER, LIGHT GND
Go to component -> Exterior lamps circuit (1 of 4) -> LH HDLP LOW TELLTALE SW SIG
