Hyundai Kona I facelift (2020-2024) left rear bumper lamp Wiring diagrams

2.0L B+2 FUSE B-CAN HIGH B-CAN LOW B/UP LP BACKUP LAMP BACKUP SIG BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM E/R JUNCTION BLOCK E/R-D ELECTROCHROMIC MIRROR GATEWAY GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START I/P-B I/P-D I/P-E I/P-G INHIBITOR SW 1 INHIBITOR SW 2 INHIBITOR SW GND INHIBITOR SW PWR INHIBITOR SWITCH IPS 2 CTRL IPS CONTROL MODULE LEFT "C" PILLAR) LEFT REAR BUMPER LAMP MULTI FUSE 2 NCA WIRE ON/START INPUT ORG/ WIRE ORG/BLK WIRE P-CAN HIGH P-CAN LOW PCB BLOCK PCM (2.0L) PNK WIRE RED WIRE RIGHT REAR BUMPER LAMP SW SIG 1 SW SIG 2 TCM (1.6L TURBO) (TOP OF TRANSAXLE) TCU 2 FUSE TRANSAXLE RANGE SW SIG D TRANSAXLE RANGE SW SIG N TRANSAXLE RANGE SW SIG P TRANSAXLE RANGE SW SIG R TRANSAXLE RANGE SWITCH YEL WIRE

10.25 INCH TFT LCD AUTO BACKUP LAMP BACKUP LAMPS CIRCUIT BCM BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRN WIRE C-CAN TRANSCEIVER COMPUTER DATA LINES SYSTEM DIMMING CIRCUIT GRN/BLK WIRE GRN/ORG WIRE GRY WIRE HEAD (LOW) HEADLIGHTS SYSTEM INSTRUMENT CLUSTER LAMP SW OUT LEFT "C" PILLAR) LEFT DRL LEFT HEADLAMP LEFT REAR BUMPER LAMP LEFT REAR COMBINATION LAMP (OUT) LEFT TURN IND LIGHT MCU (4.2 INCH COLOR LCD) MICOM (10.25 INCH TFT LCD) MULTI- FUNCTION SWITCH NCA WIRE ORG/BLK WIRE PNK/BLK WIRE RED/BLK WIRE RIGHT TURN IND SHIFT REGISTER STOP LAMP SW OUT TAIL TAIL LAMP TAIL ON IND TELLTALE T/SIG TFT BACKLIGHT I/F TFT LCD (10.25 INCH) TFT LCD DRIVE TURN ACTR TURN LAMP TURN LEFT TURN RIGHT TURN SIGNAL W/ LED W/O LED WHT WIRE

AMP AWD ECM BLK WIRE BLU WIRE ELECTRONIC MAGNETIC VALVE CLUTCH SHIELD HIGH MOUNTED STOP LAMP LEFT "C" PILLAR) LEFT BLIND-SPOT COLLISION WARNING UNIT LEFT PARKING DISTANCE WARNING REVERSE SENSOR LEFT PARKING DISTANCE WARNING- REVERSE SENSOR (CENTER) LEFT REAR BUMPER LAMP LEFT REAR COMBINATION LAMP (IN) LEFT REAR POWER WINDOW SWITCH NCA WIRE ORG/ WIRE PASSENGER OCCUPANT DETECTION SENSOR PTC HEATER REAR DEFOGGER REAR VIEW CAMERA, TAILGATE SWITCH REAR WIPER MOTOR RIGHT PARKING DISTANCE WARNING- REVERSE SENSOR (CENTER) RIGHT REAR BUMPER LAMP RIGHT REAR COMBINATION LAMP (IN) SRS CONTROL MODULE STEERING WHEEL HORN SWITCH TAILGATE LATCH W/ REAR SEAT WARMER

B/UP BLU WIRE BLU/ORG WIRE BRN WIRE BRN/BLK WIRE CONTROL ELECTROCHROMIC MIRROR EXT FROM MULTI FUSE-2 (DIAGRAM 7 OF 10) FRONT AIR VENTILATION SEAT MODULE FRONT SEAT WARMER CONTROL MODULE FRT LH FRT S/HEATER FUSE GRN/BLK WIRE GRY WIRE H/LP HI LH I/P-A I/P-B I/P-C I/P-D I/P-E IPS CONTROL MODULE LEFT DRL LEFT HEAD- LAMP LEFT HEADLAMP LEFT REAR BUMPER LAMP LEFT REAR COMBINATION LAMP (IN) LEFT REAR COMBINATION LAMP (OUT) LOW RH MEMORY POWER NCA WIRE PASSENGER POWER OUTSIDE MIRROR REAR S/HEATER FUSE REAR SEAT WARMER CONTROL MODULE REAR VIEW CAMERA, TAILGATE SWITCH RED WIRE RED/BLK WIRE RED/ORG WIRE RED/WHT WIRE RIGHT DRL RIGHT HEADLAMP RIGHT REAR BUMPER LAMP RIGHT REAR COMBINATION LAMP (IN) RIGHT REAR COMBINATION LAMP (OUT) RR RH+ TAIL FL TAIL FR TAIL RL TAIL RR TSIG W/ LED W/ SEAT WARMER W/O LED W/O SEAT WARMER
