Hyundai Kona I facelift (2020-2024) keyboard sig Wiring diagrams
This page contains all the electrical diagrams for the component. keyboard sig, in which he is found in the car Hyundai Kona I facelift (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram keyboard sig (1 of 2)
A/V, NAVIGATION HEAD UNIT
BLK WIRE
BLK/ORG WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
CAMERA B+
CAMERA GND
CAMERA P GND
CAMERA PWR
CAMERA S GND
CAMERA V/GND
CAMERA V/IN
CAMERA VIDEO (OUT)
CAMERA VIDEO GND
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
DRIVER DOOR ANTENNA, TWEETER SPEAKER
DRIVER DOOR SPEAKER
DRIVER DOOR TWEETER SPEAKER
ELECTROCHROMIC MIRROR
FL (-)
FR (-)
GRN WIRE
GRY WIRE
KEYBOARD GND
KEYBOARD SIG
LEFT REAR DOOR SPEAKER
MTS KEY IN
NCA WIRE
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PASSENGER DOOR ANTENNA, TWEETER SPEAKER
PASSENGER DOOR SPEAKER
PASSENGER DOOR TWEETER SPEAKER
REAR VIEW CAMERA
REAR VIEW CAMERA, TAILGATE SWITCH
RED WIRE
RIGHT REAR DOOR SPEAKER
RL (+)
RR (-)
SHIELD
SW GND
SW SIG
TWEETER SPEAKER
USB DTC
VEH SPD SIG
W/ NFC
W/O NFC
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Navigation circuit, w/o amplifier (1 of 3) -> KEYBOARD SIG
