Hyundai Kona I facelift (2020-2024) can 2 high local dct Wiring diagram
This page shows the only wiring diagram for the component.can 2 high local dct, which is found in the car Hyundai Kona I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram can 2 high local dct (1 of 1)
2.0L
ATM SHIFT LEVER
AWD ECM
BLK WIRE
BLU WIRE
BRN WIRE
CAN 2 HIGH LOCAL DCT
CAN 2 LOW LOCAL DCT
CCP CAN HI
CCP CAN LO
CVVD ACTUATOR
ECM (1.6L TURBO) PCM (2.0L)
ELECTRONIC OIL PUMP
FUEL PUMP CONTROL MODULE
GRN WIRE
GRY WIRE
OCCUPANT DETECTION SENSOR
ORG/ WIRE
P-CAN HI
P-CAN LO
PNK WIRE
RED WIRE
TCM (DCT)
TRANSMISSIONS SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit (3 of 4) -> CAN 2 HIGH LOCAL DCT
