Hyundai Kona I (2017-2021) fwd slide relay gnd bwd Wiring diagram
This page shows the only wiring diagram for the component.fwd slide relay gnd bwd, which is found in the car Hyundai Kona I (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fwd slide relay gnd bwd (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BWD
DOWN
DRIVER FRONT HEIGHT ADJUSTER MOTOR
DRIVER LUMBAR SUPPORT MOTOR
DRIVER REAR HEIGHT ADJUSTER MOTOR
DRIVER RECLINING
DRIVER RECLINING LIMIT SWITCH
DRIVER RECLINING, LUMBAR SUPPORT MOTOR
DRIVER SEAT MANUAL SWITCH
DRIVER SLIDE MOTOR
FWD SLIDE RELAY GND BWD
GRN WIRE
HOT AT ALL TIMES
I/P-C
IGPM
MEMORY POWER
NCA WIRE
P/SEAT (DRV) FUSE
PWR GND
RED WIRE
WHT WIRE
YEL WIRE
Go to component -> Driver power seat circuit -> FWD SLIDE RELAY GND BWD
