Hyundai Kona I (2017-2021) bcw on/off sw mode Wiring diagram
This page shows the only wiring diagram for the component.bcw on/off sw mode, which is found in the car Hyundai Kona I (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bcw on/off sw mode (1 of 1)
BCW IND
BCW LH IND
BCW ON/OFF SW IND
BCW ON/OFF SW MODE
BCW RH IND
BCW SWITCH
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
CRASH PAD SWITCH
DRIVER POWER OUTSIDE MIRROR
GRN WIRE
GRY WIRE
HOT IN ON OR START
I/P-F
IGPM
ILL
LEFT "C" PILLAR)
LEFT BLIND-SPOT COLLISION WARNING UNIT
LOCAL CAN HIGH
LOCAL CAN LOW
MODULE 4 FUSE
NCA WIRE
ON/START INPUT
ORG/ WIRE
ORG/BLK WIRE
PASSENGER POWER OUTSIDE MIRROR
PNK WIRE
PNK/BLK WIRE
RED WIRE
RIGHT BLIND-SPOT COLLISION WARNING UNIT
WHT WIRE
Go to component -> Blind spot information system circuit -> BCW ON/OFF SW MODE
