Hyundai Kona I (2017-2021) auto defogger sensor temp Wiring diagram
This page shows the only wiring diagram for the component.auto defogger sensor temp, which is found in the car Hyundai Kona I (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto defogger sensor temp (1 of 1)
A/C CONTROL MODULE
AUTO DEFOGGER ACTUATOR (ON HVAC PLENUM)
AUTO DEFOGGER ACTUATOR CLOSE
AUTO DEFOGGER ACTUATOR F/B
AUTO DEFOGGER ACTUATOR OPEN
AUTO DEFOGGER SENSOR (CENTER OF WINDSHIELD)
AUTO DEFOGGER SENSOR CURRENT
AUTO DEFOGGER SENSOR DATA
AUTO DEFOGGER SENSOR SCK
AUTO DEFOGGER SENSOR TEMP
BCM
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
CURRENT
DATA
EVAPORATOR SENSOR
GRN WIRE
GRY WIRE
ORG/ WIRE
ORG/BLK WIRE
PASS
PNK WIRE
RED WIRE
SBR
SBR PASS
SCK
SENS GND
SENS PWR
SUPPLEMENTAL RESTRAINTS SYSTEM
TELLTALE LAMP
TEMP
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (3 of 4) -> AUTO DEFOGGER SENSOR TEMP
