Hyundai IONIQ I (2016-2024) pra sensor sig Wiring diagram
This page shows the only wiring diagram for the component.pra sensor sig, which is found in the car Hyundai IONIQ I (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pra sensor sig (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/ORG WIRE
BMS ASSEMBLY
BMS CONTROL MODULE
BRN WIRE
FROM BMS CONTROL MODULE (DIAGRAM 2 OF 5)
FROM MAIN BATTERY MODULE 1 (DIAGRAM 4 OF 5)
FROM MAIN BATTERY MODULE 2 (DIAGRAM 4 OF 5)
FROM POWER RELAY ASSEMBLY (DIAGRAM 3 OF 5)
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/ORG WIRE
MAIN BATT MODULE 1 TEMP GND
MAIN BATT MODULE 1 TEMP SIG
MAIN BATT MODULE 2 TEMP GND
MAIN BATT MODULE 2 TEMP SIG
MAIN BATT MODULE 4 TEMP GND
MAIN BATT MODULE 4 TEMP SIG
MAIN BATTERY MODULE 3
MAIN BATTERY MODULE 4
MAIN BATTERY SERVICE PLUG
NCA WIRE
ORG/ WIRE
PNK WIRE
POWER HIGH VOLTAGE INSIDE
PRA SENSOR GROUND
PRA SENSOR SIG
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
SIGNAL
TO BMS CONTROL MODULE (DIAGRAM 2 OF 5)
TO POWER RELAY ASSEMBLY (DIAGRAM 3 OF 5)
VOLT SENS GND
VOLT SENS SIG
WARNING
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 1.6l hybrid, hybrid control circuit (5 of 5) -> PRA SENSOR SIG
