Hyundai IONIQ I (2016-2024) pass side impact pressure sensor high Wiring diagrams
This page contains all the electrical diagrams for the component. pass side impact pressure sensor high, in which he is found in the car Hyundai IONIQ I (2016-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pass side impact pressure sensor high (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER CURTAIN AIR BAG
DRIVER SEAT BELT ANCHOR PRETENSIONER
DRIVER SEAT BELT PRETENSIONER
DRIVER SIDE AIR BAG
DRIVER SIDE IMPACT PRESSURE SENSOR
DRIVER SIDE IMPACT SENSOR
DRV CURTAIN AIR BAG HIGH
DRV CURTAIN AIR BAG LOW
DRV SEAT BELT ANCHOR PRETENSIONER HIGH
DRV SEAT BELT ANCHOR PRETENSIONER LOW
DRV SEAT BELT PRETENSIONER HIGH
DRV SEAT BELT PRETENSIONER LOW
DRV SIDE AIR BAG HIGH
DRV SIDE AIR BAG LOW
DRV SIDE IMPACT PRESSURE SENSOR HIGH
DRV SIDE IMPACT PRESSURE SENSOR LOW
DRV SIDE IMPACT SENSOR HIGH
DRV SIDE IMPACT SENSOR LOW
GRN WIRE
ORG/ WIRE
PASS CURTAIN AIR BAG HIGH
PASS CURTAIN AIR BAG LOW
PASS SEAT BELT ANCHOR PRETENSIONER HIGH
PASS SEAT BELT ANCHOR PRETENSIONER LOW
PASS SEAT BELT PRETENSIONER HIGH
PASS SEAT BELT PRETENSIONER LOW
PASS SIDE AIR BAG HIGH
PASS SIDE AIR BAG LOW
PASS SIDE IMPACT PRESSURE SENSOR HIGH
PASS SIDE IMPACT PRESSURE SENSOR LOW
PASS SIDE IMPACT SENSOR HIGH
PASS SIDE IMPACT SENSOR LOW
PASSENGER CURTAIN AIR BAG
PASSENGER SEAT BELT ANCHOR PRETENSIONER
PASSENGER SEAT BELT PRETENSIONER
PASSENGER SIDE IMPACT PRESSURE SENSOR
RED WIRE
SRS CONTROL MODULE (BELOW CENTER CONSOLE)
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit, except hybrid (3 of 3) -> PASS SIDE IMPACT PRESSURE SENSOR HIGH
