Hyundai IONIQ I (2016-2024) hazard lamp sw arisu sig control Wiring diagram
This page shows the only wiring diagram for the component.hazard lamp sw arisu sig control, which is found in the car Hyundai IONIQ I (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hazard lamp sw arisu sig control (1 of 1)
ARISU
ARISU CONTROL
B+2 FUSE
B+3 FUSE
BACKUP LAMP
BACKUP LAMPS CIRCUIT
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
E/R JUNCTION BLOCK
GRN WIRE
GRN/BLK WIRE
HAZARD LAMP SW ARISU SIG CONTROL
HOT AT ALL TIMES
I/P-A
I/P-B
I/P-C
I/P-G
IGPM
IPS
IPS CONTROL
IPS CONTROL MODULE
MULTI FUSE 1
NCA WIRE
ORG/ WIRE
RED WIRE
RED/ORG WIRE
RIGHT REAR COMBINATION LAMP (IN)
RIGHT REAR COMBINATION LAMP (OUT)
STOP LAMP
STOP LAMP SIG
TAIL LAMP
TURN LAMP
TURN LAMP SW SIG
W/ LED
W/O LED
Go to component -> Exterior lamps circuit, electric (3 of 4) -> HAZARD LAMP SW ARISU SIG CONTROL
