Parking assistant circuit, w/o adas for Hyundai IONIQ 6 I (2022-2024)

ACC/ON INPUT AVNT KEYBOARD B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE GRY/BLK WIRE HOT W/ ACC RELAY ENERGIZED IBU (RIGHT SIDE OF DASH) ICU JUNCTION BLOCK ICU-F ILL IND LEFT REAR PDW SENSOR (IN) LEFT REAR PDW SENSOR (OUT) MODULE 2 FUSE MODULE 4 FUSE ON/START INPUT ORG/ WIRE PDW SW (IND) PDW-F PWR PDW SW SIG PDW SWITCH PDW-R PWR POWER DISTRIBUTION SYSTEM PWR RELAY ENERGIZED SIGNAL GND YEL WIRE YEL/ORG WIRE

BLK WIRE BLU WIRE BLU/ORG WIRE LEFT FRONT PDW SENSOR (IN) LEFT FRONT PDW SENSOR (OUT) ORG/ WIRE PWR RIGHT FRONT PDW SENSOR (IN) RIGHT FRONT PDW SENSOR (OUT) RIGHT REAR PDW SENSOR (IN) RIGHT REAR PDW SENSOR (OUT) YEL WIRE
