Car Wiring Diagrams for Virtual engine sound system circuit for Hyundai IONIQ 6 I (2022-2024)

BLK WIRE COMPUTER DATA LINES SYSTEM GRN/ORG WIRE GROUND HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-B M-CAN HIGH M-CAN LOW MEMORY POWER MODULE 4 FUSE ON/START INPUT ORG/BLK WIRE P/R JUNCTION BLOCK RED/ORG WIRE RELAY ENERGIZED VESS FUSE VESS SPEAKER VESS UNIT WHT WIRE
