Hyundai Genesis II (2013-2016) led device ic Wiring diagram

B-CAN HIGH B-CAN LOW B-CAN TRANSCEIVER BCM (UNDER FRONT OF CENTER CONSOLE) BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM DOOR DOOR OPEN IND DRIVER DOOR LAMP DRIVER DOOR SCUFF LAMP DRIVER DOOR SW DRIVER DOOR SWITCH (ON DRIVER "B" PILLAR) GRN WIRE GRN/BLK WIRE GRY WIRE HIGH COMPUTER DATA LINES LOW SYSTEM HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START I/P-C I/P-D I/P-G INSTRUMENT CLUSTER IPS CONTROL MODULE LEAK CURRENT AUTOCUT DEVICE LED DEVICE IC LEFT "C" PILLAR) LEFT VANITY LAMP MAP LAMP MICOM MODULE 1 FUSE MODULE 2 FUSE MOOD LAMP OFF ORG/ WIRE OVERHEAD CONSOLE PASSENGER DOOR LAMP PASSENGER DOOR SCUFF LAMP PASSENGER DOOR SW PASSENGER DOOR SWITCH (ON PASSENGER "B" PILLAR) PNK WIRE PNK/BLK WIRE POWER WINDOWS SYSTEM RED WIRE RIGHT VANITY LAMP ROOM LAMP ROOM LP FUSE SMART JUNCTION BOX TRUNK LID LATCH TRUNK OPEN IND TRUNK ROOM LAMP TRUNK ROOM LAMP SWITCH TRUNK SW YEL WIRE
