Shift & key lock circuit for Hyundai Genesis I facelift (2011-2016)

"P" POSITION ATM SWITCH SOLENOID ACC INPUT GROUND "P" POS SW 11 12 BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE CRUISE CONTROL SYSTEM E/R JUNCTION BOX (RIGHT REAR OF ENGINE COMPT) E/R-CA E/R-CB GRN WIRE HOT AT ALL TIMES LEFT I/P SECURITY JUNCTION BOX LP (LEFT END FUSE OF DASH) HOT IN ACC OR ON HOT IN ON OR START I/P-LHA I/P-RHB IPM JOINT CONNECTOR JMC (RIGHT END OF DASH) JOINT CONNECTOR JME (BEHIND CENTER OF DASH) MODULE 2 FUSE ON/START IN ORG/ WIRE PNK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM RED WIRE RIGHT I/P JUNCTION BOX (RIGHT END OF DASH) SPD SIG SPORT MODE SWITCH STOP SIG ATM SOLENOID TRANSMISSION RANGE SWITCH (RIGHT SIDE OF TRANSMISSION) TRANSMISSIONS SYSTEM WHT WIRE WHT/BLK WIRE YEL WIRE
