2.0l turbo, cruise control circuit for Hyundai Genesis I facelift (2011-2016)

1 2 PNK WIRE ACCELERATOR PEDAL POSITION SENSOR (ACCELERATOR PEDAL ASSEMBLY) BLK WIRE BLU WIRE BLU/ORG WIRE BRAKE SW FUSE BRN WIRE CANCEL CRUISE MAIN SWITCH SWITCH CLOCK- SPRING CLUTCH SW COMPUTER DATA LINES SYSTEM ECM (LEFT REAR OF ENGINE COMPT) ETC MOTOR, THROTTLE POSITION SENSOR (ON THROTTLE BODY) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES SMART JUNCTION BOX HOT IN ON OR START I/P-A I/P-C I/P-E J/C LEAK CURRENT AUTOCUT DEVICE MEMORY 1 FUSE LEFT E/R JUNCTION BOX MODULE 2 FUSE MODULE 3 FUSE MOTOR NCA WIRE ORG/ WIRE PNK WIRE RED WIRE RED/BLK WIRE RESUME/ ACCEL SWITCH ILL RIGHT CRUISE REMOTE CONTROL SWITCH SET/ COAST SWITCH STEERING WHEEL) STOP LAMP SWITCH (BRAKE PEDAL BRACKET) STOP LP FUSE STOP SIGNAL RELAY (LEFT SIDE OF DASH) THROTTLE POSITION SENSOR WHT WIRE YEL WIRE

1 2 PNK WIRE A/V, NAVIGATION HEAD UNIT AUDIO AUTO HEADLAMP LEVELING DEVICE UNIT (LEFT REAR SUSPENSION) BLK WIRE BLU WIRE BRN WIRE C-CAN COMPUTER DATA LINES SYSTEM CRUISE IND CRUISE SET IND DATA LINK CONNECTOR (LOWER LEFT SIDE OF DASH) ESC UNIT ESC MODULE (LEFT FRONT OF ENGINE COMPT) GRN WIRE GRY WIRE GRY/ORG WIRE HID INSTRUMENT CLUSTER J/C LED DRIVE IC LEFT FRONT WHEEL SENSOR (LEFT FRONT WHEEL HUB ASSEMBLY) LEFT REAR WHEEL SENSOR (LEFT REAR WHEEL HUB ASSEMBLY) MICOM NCA WIRE ORG/ WIRE PNK WIRE RED WIRE REDUCING LIGHT IC REGULATOR RIGHT FRONT WHEEL SENSOR (RIGHT FRONT WHEEL HUB ASSEMBLY) RIGHT REAR WHEEL SENSOR (RIGHT REAR WHEEL HUB ASSEMBLY) S GND SPEEDOMETER TACHOMETER TRANSCEIVER B-CAN TRANSCEIVER/ W/ NAVIGATION W/O NAVIGATION WHT WIRE YEL WIRE
