Hyundai Genesis I facelift (2011-2016) low computer data lines system b-can high Wiring diagram
This page shows the only wiring diagram for the component.low computer data lines system b-can high, which is found in the car Hyundai Genesis I facelift (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low computer data lines system b-can high (1 of 1)
ACTUATOR SIG
AUTO HEAD TAIL
AUTO HEADLAMP LEVELING DEVICE UNIT (LEFT REAR SUSPENSION)
B-CAN B-CAN HIGH LOW
BCM (UNDER FRONT OF CENTER CONSOLE)
BLK WIRE
BLU WIRE
BODY K-LINE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
DIMMER/PASSING SWITCH
FUSE
GRN WIRE
GROUND
GRY WIRE
H/LP (LO) ON SIG
HEAD LAMP HI SW
HEAD LAMP LO SW
HEAD- LAMP
HEADLAMP LOW SIGNAL
HOT IN ON OR START
I/P-D
I/P-E
I/P-G
JOINT CONNECTOR
LEFT E/R JUNCTION BOX
LEFT HEADLAMP LEVELING DEVICE ACTUATOR (BEHIND LEFT HEADLAMP ASSEMBLY)
LO SIG
LOW COMPUTER DATA LINES SYSTEM B-CAN HIGH
LOW HIGH
MODULE
MULTI- FUNCTION SWITCH
OFF LIGHT SWITCH
ON INPUT
ORG/ WIRE
PASS
POWER DISTRIBUTION SYSTEM
RED WIRE
RIGHT HEADLAMP LEVELING DEVICE ACTUATOR (BEHIND RIGHT HEADLAMP ASSEMBLY)
SMART JUNCTION BOX
VEH SPD SENS
W/ HID
W/ REAR PARKING ASSIST SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Headlamps leveling circuit -> LOW COMPUTER DATA LINES SYSTEM B-CAN HIGH
