Hyundai Genesis I facelift (2011-2016) left rear combination Wiring diagram
This page shows the only wiring diagram for the component.left rear combination, which is found in the car Hyundai Genesis I facelift (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear combination (1 of 1)
A/T
A/T M/T
A/V, NAVIGATION HEAD UNIT
B/UP LP FUSE
BACKUP LAMP
BACKUP LAMP SWITCH (LEFT SIDE OF TRANSMISSION)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
COMPT)
ELECTROCHROMIC MIRROR
GRY WIRE
HOT IN ON OR START
I/P-A
I/P-E
I/P-F
IPS CONTROL SHIFT MODULE LEVER 'R'
LAMP
LEFT "C" PILLAR)
LEFT E/R JUNCTION BOX (LEFT SIDE OF ENGINE
LEFT REAR COMBINATION
M/T
NCA WIRE
ON/START INPUT
ORG/ WIRE
PNK (OR WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
RIGHT REAR COMBINATION
SIGNAL 1
SIGNAL 2
SIGNAL 3
SIGNAL 4
SMART JUNCTION BOX
TCM (LEFT REAR OF ENGINE COMPT)
TRANSAXLE RANGE SWITCH (LEFT SIDE OF TRANSAXLE)
W/ NAVIGATION
YEL WIRE
Go to component -> Backup lamps circuit -> LEFT REAR COMBINATION
