Hyundai Genesis I facelift (2011-2016) left front smart outside handle Wiring diagram
This page shows the only wiring diagram for the component.left front smart outside handle, which is found in the car Hyundai Genesis I facelift (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front smart outside handle (1 of 1)
BLK WIRE
BLK/ORG WIRE
CAMERA MODULE
DRIVER DOOR LOCK ACTUATOR
DRIVER DOOR MODULE
DRIVER POWER WINDOW MODULE
ELECTRO- CHROMIC MIRROR
FORWARD, REAR PARKING ASSIST CONTROL MODULE
FRONT ROOM LAMP
FUEL FILLER DOOR MOTOR
FUEL FILLER DOOR SWITCH
FUEL SENDER, FUEL PUMP MOTOR
GRN WIRE
IMS CAMERA CONTROL MODULE MODULE
IMS SWITCH
JOINT CONNECTOR JDDRI (DRIVER'S DOOR)
JOINT CONNECTOR JFLA (LEFT "C" PILLAR)
JOINT CONNECTOR JFLB (LEFT "C" PILLAR)
JOINT CONNECTOR JRA (LEFT FRONT OF HEADLINER)
LEFT "C" PILLAR)
LEFT FRONT SMART OUTSIDE HANDLE
LEFT POWER OUTSIDE MIRROR
LEFT REAR COMBINATION LAMP (OUT)
LEFT REAR DOOR LOCK ACTUATOR
LEFT REAR DOOR MODULE
LEFT REAR SEAT WARMER MODULE
LEFT VANITY LAMP
NAVIGATION
NCA WIRE
OVERHEAD CONSOLE LAMP
OVERHEAD LDWS CONSOLE MODULE LAMP
REAR CURTAIN SWITCH
REAR CURTAIN, IMS SWITCH
REAR PASSENGER CURTAIN DOOR MODULE MODULE
REAR ROOM LAMP
RIGHT REAR SEAT WARMER MODULE
RIGHT VANITY LAMP
SUNROOF SWITCH
Go to component -> Ground distribution circuit (4 of 6) -> LEFT FRONT SMART OUTSIDE HANDLE
