Hyundai Genesis I facelift (2011-2016) ips control module b/alarm relay Wiring diagram
This page shows the only wiring diagram for the component.ips control module b/alarm relay, which is found in the car Hyundai Genesis I facelift (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ips control module b/alarm relay (1 of 1)
2.0L TURBO 3.8L
3.8L
B/ALARM RELAY
BATTERY
BLK WIRE
BLU/ORG WIRE
CHARGING CIRCUIT
CONTROL
CRANK RELAY REQUEST CONTROL
ECM (LEFT REAR OF ENGINE COMPT)
ELG-A CLG-B
FUSE
GRN WIRE
I/P-B
I/P-D
ICM RELAY BOX (LEFT SIDE OF DASH)
IGNITION SWITCH
IPS CONTROL MODULE B/ALARM RELAY
J/C
LEFT E/R JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
LOCK
MOTOR
ORG/ WIRE
P/N SW
PNK WIRE
RED WIRE
RELAY
RUN WIRE
SMART JUNCTION BOX
SOLENOID
TRANSAXLE RANGE SWITCH (LEFT SIDE OF TRANSAXLE)
W/ IMMOBILIZER
W/O IMMOBILIZER
WHT WIRE
Go to component -> Starting circuit, a/t without button start -> IPS CONTROL MODULE B/ALARM RELAY
