Hyundai Genesis I facelift (2011-2016) from joint connector Wiring diagram
This page shows the only wiring diagram for the component.from joint connector, which is found in the car Hyundai Genesis I facelift (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram from joint connector (1 of 1)
A/C CONTROL MODULE
A/T
AUTO GLOVE HEADLAMP BOX LAMP LEVELING SWITCH DEVICE UNIT
AUTOMATIC A/C
AUTOMATIC A/C TO GROUND
BATTERY
BCM
BLK WIRE
BLK/ORG WIRE
BLOWER RELAY
CLOCK- SPRING
CLUSTER IONIZER
DATA LINK CONNECTOR
DOOR DOOR LOCK UNLOCK RELAY RELAY
ELECTROCHROMIC MIRROR
ESC, PAS SWITCH
FET (FIELD EFFECT TRANSISTOR)
FROM JOINT CONNECTOR
FRONT FOG LAMP SWITCH
GND GND
I/P-B
I/P-D
INSTRUMENT CLUSTER
INSTRUMENT TRIP STEERING RHEOSTAT CLUSTER SWITCH ANGLE SENSOR
IPS CONTROL MODULE
JOINT
JOINT CONNECTOR
LEFT RIGHT HEADLAMP HEADLAMP LEVELING LEVELING DEVICE DEVICE ACTUATOR ACTUATOR
LEFT VANITY LAMP
M/T
MANUAL A/C
MAP LAMP
MULTI FUNCTION SWITCH (REMOTE CONTROL)
MULTI GAUGE
MULTI- FUNCTION SWITCH
NCA WIRE
OVERHEAD CONSOLE
PDM
QUARTER PANEL GROUND
REAR DEFOGGER
RIGHT VANITY LAMP
SMART JUNCTION BOX
SMART KEY CONTROL MODULE
SPORT MODE SWITCH
STEERING WHEEL)
STOP SIGNAL RELAY
SUNROOF CONTROL MODULE
SUNROOF SWITCH
TIRE PRESSURE MONITORING MODULE
TWO TURN UNLOCK RELAY
W/ BUTTON
W/O BUTTON
WIPER SWITCH
YEL WIRE
Go to component -> Ground distribution circuit (1 of 4) -> FROM JOINT CONNECTOR
