Hyundai Genesis I facelift (2011-2016) engine ctrl relay on input ftps gnd iat sensor apt signal pnk wiring diagram
This page shows the only wiring diagram for the component.engine ctrl relay on input ftps gnd iat sensor apt signal pnk, which is found in the car Hyundai Genesis I facelift (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
engine ctrl relay on input ftps gnd iat sensor apt signal pnk wiring diagram (1 of 1)
ACCELERATOR PEDAL POSITION SENSOR (ACCELERATOR PEDAL ASSEMBLY)
APT SENSOR GND OTS SIGNAL TPS SENSOR GND APS 1 POWER
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
CKPS GND VEHICLE SPEED SIG INPUT
ECM (LEFT REAR OF ENGINE COMPT)
ENGINE CTRL RELAY ON INPUT FTPS GND IAT SENSOR APT SIGNAL PNK WIRE
ESC MODULE (LEFT FRONT OF ENGINE COMPT)
EWGA F/B SENS SIG
GRN WIRE
GRY WIRE
INJECTOR 1 INJECTOR 3 INJECTOR 4 INJECTOR 2
INSTRUMENT CLUSTER SYSTEM
OIL TEMPERATURE SENSOR (LEFT FRONT OF CYLINDER HEAD)
ORG/ WIRE
PNK OXYGEN SENSOR (UP) V-RC SENSOR POWER WIRE
PNK WIRE
PNK/BLK WIRE
RCV CONTROL
RED WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo (1 of 6) -> ENGINE CTRL RELAY ON INPUT FTPS GND IAT SENSOR APT SIGNAL PNK WIRE
