Car Wiring Diagrams for Headlamps leveling circuit, with afls for Hyundai Genesis I (2008-2011)

6 9 10 18 LOW SIG GROUND K-LINE ON/START INPUT ADAPTIVE FRONT LIGHT MODULE (RIGHT CENTER OF DASH) ADAPTIVE FRONT LIGHTING CIRCUIT AFLS FUSE BLK WIRE BLU WIRE BLU/BLK WIRE COMPUTER DATA LINES SYSTEM GRN WIRE GRN/ORG WIRE HEAD LAMP (LOW) RELAY HEADLAMPS CIRCUIT HOT AT ALL TIMES HOT IN ON ENGINE ROOM JUNCTION AQS FUSE BLOCK (RIGHT REAR OF ENGINE COMPT) HOT IN ON OR START HOT IN ON OR START LEFT I/P JUNCTION BOX I/P-LHA ISM J/C JEFEM (FRONT OF ENGINE COMPT) J/C JME (BEHIND CENTER OF DASH) LEFT HEADLAMP LEFT HLLD ACTUATOR MULTI- FUNCTION SWITCH NCA WIRE PNK/BLK WIRE RIGHT HLLD ACTUATOR RIGHT HEADLAMP STEP MTR HLLD ACTR STEP MTR ISM HLLD ACTR WHT/BLK WIRE WHT/ORG WIRE
