Hyundai Genesis I (2008-2011) transponder interface Wiring diagram
This page shows the only wiring diagram for the component.transponder interface, which is found in the car Hyundai Genesis I (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transponder interface (1 of 1)
3.8L
4.6L
72 27 ELG-A 36 CTG-A 67 CTG-K IMMO IND IMMO SIG
ANTENNA COIL
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BODY UNIT-2 FUSE
COMMS INTERFACE
DOOR WARNING SWITCH
ECM (3.8L: LEFT REAR OF ENGINE COMPT) (4.6L: LEFT SIDE OF ENGINE COMPT)
ENG SNSR 2 FUSE
ENGINE ROOM JUNCTION BLOCK (RIGHT REAR OF ENGINE COMPT)
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ENGINE CONTROL RELAY ENERGIZED
I/P-LHF
IGNITION KEY
IMMO IND
IMMO SIG
IMMOBILIZER IND
IMMOBILIZER MODULE (LEFT SIDE OF DASH)
INSTRUMENT CLUSTER
J/C JME (BEHIND CENTER OF DASH)
LEFT I/P JUNCTION BOX
NCA WIRE
ORG/ WIRE
PCU
PNK/BLK WIRE
TRANSPONDER
TRANSPONDER INTERFACE
VOLTAGE CONDITIONING
Go to component -> Immobilizer circuit, without button start -> TRANSPONDER INTERFACE
