Hyundai Genesis I (2008-2011) sbr ind Wiring diagram
This page shows the only wiring diagram for the component.sbr ind, which is found in the car Hyundai Genesis I (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sbr ind (1 of 1)
17 18 PNK WIRE
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
DRV SEAT BELT SW
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/ORG WIRE
HI LO
I/P-LHA
I/P-LHF
I/P-LHH
IMPACT SENSOR
IPM (INSTRUMENT PANEL MODULE) (LEFT SIDE OF DASH)
LEFT FRONT SIDE AIR BAG (LEFT SIDE OF DRIVER'S SEAT BACK)
LEFT FRONT SIDE IMPACT SENSOR (BASE OF LEFT "B" PILLAR)
LEFT I/P JUNCTION BOX
LEFT REAR SIDE IMPACT SENSOR (LEFT "C" PILLAR)
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
RED WIRE
RED/ORG WIRE
RIGHT FRONT SIDE IMPACT SENSOR (BASE OF RIGHT "B" PILLAR)
RIGHT REAR SIDE IMPACT SENSOR (RIGHT "C" PILLAR)
SBR
SBR IND
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraints circuit (2 of 3) -> SBR IND
