Hyundai Genesis I (2008-2011) ehps module Wiring diagrams
This page contains all the electrical diagrams for the component. ehps module, in which he is found in the car Hyundai Genesis I (2008-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ehps module (1 of 2)
3.8L
3.8L, 4.6L
ACC SOCKET RELAY
AQS SENSOR
AUTO HEADLAMP LEVELING LEFT DEVICE HEADLAMP SENSOR
BLK WIRE
BLOWER RELAY
BRAKE FLUID LEVEL SENSOR
BUTTON
COOLING FAN CONTROLLER
COOLING MULTIPURPOSE FAN RELAY CHECK CONNECTOR
EHPS MODULE
ELECTRONIC CONTROL WIPER MODULE
ENGINE ROOM JUNCTION BLOCK
ESC CONTROL MODULE
ESCL (ACC) RELAY RELAY
EXTERNAL BUZZER
FAM
FAM-B
FAM-C
FOB HOLDER
HOOD SWITCH
JOINT CONNECTOR JEB (LEFT KICK PANEL)
JOINT CONNECTOR JEFEM (FRONT OF ENGINE COMPT)
LEFT FRONT BURGLAR FOG ALARM LAMP HORN
LEFT HEADLAMP
NCA WIRE
PDM
RELAY
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
RIGHT LEFT HEADLAMP HORN
SMART CRUISE RIGHT CONTROL HORN MODULE
SPORT MODE SWITCH
SUB START RELAY
WASHER LEVEL SENSOR
WASHER MOTOR
WHT WIRE
WINDSHIELD DEFOGGER
Go to component -> Ground distribution circuit (2 of 5) -> EHPS MODULE
Wiring diagram ehps module (2 of 2)
ABS 1 FUSIBLE LINK
ABS 2 FUSIBLE LINK
ALT FUSIBLE LINK
AMP
AVJBL AMP
B/UP LP FUSE AMP 1 FUSIBLE LINK
BACKUP LAMP RELAY (4.6L)
BLK WIRE
BLU/ORG WIRE
BRN WIRE
COOLING FAN RELAY
COOLING FUSIBLE LINK
DRL FUSE I/P LH PWR FUSIBLE LINK
DRL RELAY
EHPS FUSIBLE LINK
EHPS MODULE
ESC CONTROL DRIVER MODULE POWER SEAT RELAY BOX
ESCL (ACC) RELAY (W/ BUTTON START)
ESCL (IGN 1) FUSIBLE LINK
ESCL (IGN 1) RELAY (W/ BUTTON START)
ESCL (IGN 2) FUSIBLE LINK
ESCL (IGN 2) RELAY (W/ BUTTON START)
FROM ALT FUSIBLE LINK (DIAGRAM 2 OF 7)
FROM JOINT BOX (DIAGRAM 1 OF 7)
FRONT LUMBAR SUPPORT SWITCH
GENERATOR
GRN WIRE
GRY WIRE
I/P RH PWR FUSIBLE LINK
IMS CONTROL DRIVER MODULE POWER SEAT RELAY BOX
IPM (W/ BUTTON START)
J/C JEB (LEFT KICK PANEL)
MULTI-PURPOSE CHECK CONNECTOR
ORG/ WIRE
ORG/BLK WIRE
P/SEAT F/L FUSE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/BLK WIRE
SOCKET ESCL (ACC) FUSE FUSIBLE AMP 2 LINK FUSIBLE LINK
STOP LAMP RELAY
STOP LAMP SWITCH
STOP LP FUSE
T/LID FUSE
TO ACC SOCKET RELAY (DIAGRAM 6 OF 7)
TO COOLING FUSIBLE LINK (DIAGRAM 2 OF 7)
TO LEFT I/P JUNCTION BOX (DIAGRAM 3 OF 7)
TO LEFT I/P JUNCTION BOX (DIAGRAM 4 OF 7) J/C
TO P/OUTLET (RR) FUSE (DIAGRAM 6 OF 7)
TO PDM (DIAGRAM 7 OF 7)
TO RIGHT I/P JUNCTION BOX (DIAGRAM 5 OF 7)
TO RIGHT I/P JUNCTION BOX (DIAGRAM 6 OF 7)
TRUNK LID RELAY
W/ IMS W/O IMS
W/O IMS W/ IMS
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Power distribution circuit (2 of 7) -> EHPS MODULE
