Hyundai Equus II facelift (2013-2016) switch c-can low c-can high b-can low b-can high Wiring diagram
This page shows the only wiring diagram for the component.switch c-can low c-can high b-can low b-can high, which is found in the car Hyundai Equus II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram switch c-can low c-can high b-can low b-can high (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
CRASH PAD SWITCH
GRN WIRE
GRN/BLK WIRE
GROUND
HEADUP DISPLAY
HOT AT ALL TIMES
HOT AT ALL TIMES LEFT SMART JUNCTION BOX EPB (LEFT END FUSE OF DASH)
HOT W/ PDM
HUD SWITCH
I/P-LHF
I/P-LHG
I/P-RHD
IPS CONTROL MODULE
JOINT CONNECTOR
MEMORY POWER ON/START INPUT
MODULE 1 FUSE
MODULE FUSE
ON INPUT
ORG/ WIRE
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RIGHT I/P JUNCTION BOX (RIGHT END OF DASH)
SWITCH C-CAN LOW C-CAN HIGH B-CAN LOW B-CAN HIGH
WHT WIRE
YEL WIRE
Go to component -> Head-up display circuit -> SWITCH C-CAN LOW C-CAN HIGH B-CAN LOW B-CAN HIGH
