Hyundai Equus II facelift (2013-2016) left right turn signal lamp switch Wiring diagram
This page shows the only wiring diagram for the component.left right turn signal lamp switch, which is found in the car Hyundai Equus II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left right turn signal lamp switch (1 of 1)
A/BAG FUSE
AUTO
BCM (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/ORG WIRE
CENTER FASCIA SWITCH
COMPUTER DATA LINES SYSTEM
E/R FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
HOT AT ALL TIMES
I/P-LHF
JOINT CONNECTOR
LEFT I/P JUNCTION BOX
LEFT RIGHT
LEFT RIGHT TURN SIGNAL LAMP SWITCH
LICENSE LAMP
LIGHT SWITCH
M/F SW ECU
MULTI- FUNCTION SWITCH
NCA WIRE
OFF
ORG/BLK WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
SBR IND
STOP LAMP FUSE
TELLTALE LAMP
TRUNK LID HANDLE SWITCH
TRUNK LID HANDLE SWITCH, LICENSE LAMP
TRUNK, TAILGATE, FUEL DOORS SYSTEM
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
YEL WIRE
