Hyundai Equus II facelift (2013-2016) 14 13 memory pwr start feed/ back sig Wiring diagram

14 13 MEMORY PWR START FEED/ BACK SIG BATTERY BATTERY, BATTERY FUSE BOX (RIGHT SIDE OF TRUNK) BLK WIRE BLU WIRE BLU/BLK WIRE BRN/WHT WIRE E/R JUNCTION BOX E/R JUNCTION BOX (RIGHT REAR OF ENGINE COMPT) E/R-CTA E/R-CTB ECM (LEFT REAR OF ENGINE COMPT) ELECTRONIC BATTERY SENSOR (NEGATIVE BATTERY TERMINAL) FUSE HOT AT ALL TIMES I/P-LHE JOINT BOX LEFT SMART JUNCTION BOX (LEFT END OF DASH) MOTOR NCA WIRE ORG/BLK WIRE P/N SWITCH (P/N POSITION SWITCH CLOSE) RED WIRE RELAY RLY O/P SIG (I/P) SMART KEY CONTROL MODULE (UNDER LEFT SIDE OF DASH) SOLENOID START RLY START/STOP BUTTON SWITCH STOP LAMP FUSE TRANSMISSION RANGE SWITCH (LEFT SIDE OF TRANSMISSION) WHT WIRE YEL WIRE YEL/BLK WIRE
