Wiring diagram 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 memory power memory power acc/on input (1 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 MEMORY POWER MEMORY POWER ACC/ON INPUT
ACC/ON INPUT
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FRONT DIS SWITCH (CENTER OF FLOOR CONSOLE)
FRONT MONITOR
FRT B/L ON/OFF
GRY WIRE
HOT AT ALL TIMES
I/P-LHC
I/P-LHG
ILL
JOINT CONNECTOR
LEFT
LH RR ON/OFF
M-CAN HI
M-CAN HI GND
M-CAN LO
M-CAN LO GND
MEMORY PWR
MULTI MEDIA FUSE SMART JUNCTION BOX (LEFT END OF DASH)
PNK 13 14 WIRE
PNK 7 8 WIRE
PNK PNK WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RH RR ON/OFF
RR LOCK DET
RR PND
SPLIT UNIT (UNDER CENTER FLOOR CONSOLE)
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit (3 of 6) -> 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 MEMORY POWER MEMORY POWER ACC/ON INPUT
